Technical Manual Glass Push Button II Smart BE-GT2xx.01
The following table shows the available communication objects:
Number Name
0 Push button 1 – send
status
3 Push button 1 –
State for display
Table 29: Communication objects - Single- utton fun tion „" it h -"send status with on-delay"

4.3.1.6 Sub-function: Send status with off-delay

Single-button function
In the single-button function "Switch" - Sub-function: Send status with switch-off delay, the key
sends the value "On" for pressing the key and the value "Off" for releasing the key. However, the
value "Off" is delayed by the set time delay.
The following figure shows the available settings:
Figure 21: Settings: Single- utton fun tion „" it h -"send status with off-delay"
The following table shows the available communication objects:
Number Name
0 Push button 1 – send
status
3 Push button 1 –
State for display
Table 30: Communication objects - Single- utton fun tion „" it h -"send status with off-delay"
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
51
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Length Usage
1 Bit Switch function of the button
1 Bit State to refresh the display/symbol on the
button; has to be connected to the state of the
actuator to be switched
Length Usage
1 Bit Switch function of the button
1 Bit State to refresh the display/symbol on the
button; has to be connected to the state of the
actuator to be switched
