Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.3.1 Switch

The following figure shows the available settings for the push button function "Switch"
(here the example with the two-button function):
Figure 14: Settings: Push button function - Switch
The following parameters are identical for all sub-functions of the button function "Switch":
ETS-Text
Assignment of push buttons
Subfunction
Table 24: Identical Parameter - Switch
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
47
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
On/Off
Off/On
switch
toggle
send status
send status with
on-delay
send status with
off-delay
Comment
Setting available only for the
two-button function; defines
the sending behavior of the left
and right buttons
Setting available only for the
single-button function; defines
the subfunction and, if
necessary, displays further
parameters
