Technical Manual Glass Push Button II Smart BE-GT2xx.01
2 Overview
2.1 Overview devices
The description refers to the following devices (order number in bold):
BE-GT20W.01 Glass Push Button II Smart, white
o Second generation of Glass Push Button with up to 12 key functions
BE-GT20S.01 Glass Push Button II Smart, black
o Second generation of Glass Push Button with up to 12 key functions
BE-GT2TW.01 Glass Push Button II Smart, white, temperature sensor
o Second generation of Glass Push Button with up to 12 key functions and
integrated temperature sensor
BE-GT2TS.01 Glass Push Button II Smart, black, temperature sensor
o Second generation of Glass Push Button with up to 12 key functions and
integrated temperature sensor
2.1.1 Special functions of the Glass Push Button II Smart
The Glass Push Button II Smart has a very extensive application with the following special functions:
Large RGB color display for visualization
Large, active color display for function- and status indication can be freely parameterized by the user.
The symbols and colors are freely selectable!
Symbols can be reloaded via DCA App
A free DCA app can be used to reload and parameterize any image of the size 64x64 pixels!
Can be used as a 4/6/8/12-button
Up to 3 levels with up to 4 functions per level can be activated. Thus, the button can control up to 12
functions. The levels as well as the functions can be named individually. The selection of the levels is
made via the upper two buttons, the call of the individual functions via the 4 buttons below.
Extensive application
The function range of the application exceeds that of a "normal" push button by a multiple. In
addition to the usual functions such as blinds, switching, dimming, scene, the user is also provided
with functions for controlling the HSV color circle or a function for controlling the color temperature
(Tunable White). The button contains special symbols to control and visualize these functions!
RGB State LEDs
An RGB status LED is available to the user for each function. This can visualize both, a keystroke as
well as an external or internal status with any color.
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
4
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
