- Page 1 6/2014 Technical Manual MDT Switch Actuators with current measurement AMI/AMS R2.x nd Hardware Revision) MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 2: Table Of Contents
4.4.1 Overview .......................... 20 4.4.2 On/Off delay ......................... 22 4.4.3 Logical functions ........................ 23 4.4.4 Scene function ........................ 25 4.5 Staircase ............................ 30 4.5.1 Overview .......................... 30 4.5.2 Staircase time ........................ 32 4.5.3 Prewarning und Warning ..................... 33 4.5.4 Manual switch off ......................... 34 4.5.5 Extend staircase time ...................... 34 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 3 4.7.2 Reverse counter ........................ 44 5 Index .............................. 46 5.1 Register of illustrations ........................ 46 5.2 List of tables.......................... 47 6 Attachment ............................ 48 6.1 Statutory requirements ....................... 48 6.2 Routine disposal .......................... 48 6.3 Assemblage .......................... 48 6.4 Group state .......................... 49 6.5 Datasheet ............................ 50 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 4: 2 Overview
8 TE REG, 230VAC, 16A, C‐Load 100uF, with current measurement AMS‐1216.01 Switching actuator 12‐fold,4TE, 230V AC, 16 A, C‐Load 100µF, standard design o 12 TE REG, 230VAC, 16A, C‐Load 100uF, with current measurement AMI‐0416.01 Switching actuator 4‐fold,4TE, 230V AC, 16 A, C‐Load 200µF, industrial design o 4 TE REG, 230VAC, 16A, C‐Load 200uF, with current measurement AMI‐0816.01 Switching actuator 8‐fold,8TE, 230V AC, 16 A, C‐Load 200µF, industrial design o 8 TE REG, 230VAC, 16A, C‐Load 200uF, with current measurement AMI‐1216.01 Switching actuator 12‐fold,8TE, 230V AC, 16 A, C‐Load 200µF, industrial design o 12 TE REG, 230VAC, 16A, C‐Load 200uF, with current measurement MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 5: Exemplary Circuit Diagrams
Technical Manual Switch Actuators AMI/AMS 2.2 Exemplary circuit diagrams Figure 1: Exemplary circuit diagram AMS‐0816.01 Figure 2: Exemplary circuit diagram AMI‐1216.01 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 6: Structure & Handling
Technical Manual Switch Actuators AMI/AMS 2.3 Structure & Handling The switch actuators (here: AKI 1216.01) contain of one status LED per channel. This LED indicates the state of the depending output. Furthermore every output can be switched manual, independent of the current parameterization. The lines AKS and AKI have buttons for every channel. In contrast the line of the AKK has only four buttons, independent to the number of channels. Two buttons are for choosing the channel, whereby the chosen channel is indicated by a flashing status LED. The buttons up and down are for switching the channel on and off. The programming button activates the programming function. An activated programing function is indicated by a lit programming LED. Figure 3: Overview hardware module switch actuator (e.g. AMI‐1216.01) The lines AMS and AMI have bistable relays. At the bistable relays the current switching state also stays in case of a breakdown of the 230V auxiliary voltage and at an update of the parameterization. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 7: Functions
Scenes scene function for up to 8 scenes per channel Status functions feedback function cyclic send able “operating‐state” telegram group state of all channels Current measurement single current measurement of each channel warning and error messages adjustable total current measurement of the whole device Electric meter functions counting of the current consumption of every channel counting of the current consumption of the whole actuator Operating hours counter forward counter of the operating hours back counter to next service time Table 1: Overview functions MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 8: Settings At The Ets-Software
2.6. Starting up After wiring, the allocation of the physical address and the parameterization of every channel follow: (1) Connect the interface with the bus, e.g. MDT USB interface (2) Switching the power supply (3) Set bus power up (4) Press the programming button at the device(red programming LED lights) (5) Loading of the physical address out of the ETS‐Software by using the interface(red LED goes out, as well this process was completed successful) (6) Loading of the application, with requested parameterization (7) If the device is enabled you can test the requested functions(also possible by using the ETS‐ Software) MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 9: 3 Communication Objects
Status feedback function DPT 1.001 Out, Read 6 Logic 1 only shown at activated logic function DPT 1.001 In, Write 7 Logic 2 only shown at activated logic function DPT 1.001 In, Write +18 next channel Table 2: Communication objects “switch” MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 10: Central Communication Object
Switch on/off central switching function In, Write DPT 1.001 Operating sends cyclic if the actuator answers at the bus Out, Send DPT 4.001 Group State sends the state of all channels Out, Send DPT 1.001 Manual Control blocks the manual control In, Write Table 4: Central communication object MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 11: Communication Objects Current Measurement
Out, Read DPT 14.019/ activated channels DPT 9.024 77/149 Exceedance of total reports an exceeded load of all Out, Read DPT 1.001 current activated channels Table 5: Communication objects current measurement The sizes as well as the type of the shown objects depends to the adjusted parameterization, have a look at the relevant explanations at section 4. There are objects for the current measurement of the single channels as well as for the total current measurement of the actuator. It can be adjusted whether a channel shall be included to the total current measurement or not. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 12: Default Settings Of The Communication Objects
X 77/149 Central function Exceedance of total current 1 Bit Low X X 78/150 Central function switch on/off 1 Bit Low X Table 6: Communication objects – default settings You can see the default values for the communication objects from the upper chart. According to requirements the priority of the particular communication objects as well as the flags can be adjusted by the user. The flags allocates the function of the objects in the programming thereby stands C for communication, R for Read, W for write, T for transmit and U for update. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 13: 4 Reference Ets-Parameter
not active measurement, have a look at chapter 4.6.2 total current Table 7: General settings The following chart shows the relevant communication objects: Number Name Length Usage Operating 1 Bit sends cyclic, if the actuator is at the bus Group state 4 Byte sends the state of all channels Table 8: Communication objects general functions MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 14: Channel Selection
There are 3 possible states for every channel, which can be adjusted at the menu “channel preselection”. The following parameterization accords to the chosen state of a channel. But if you chosse a channel as “not active”, there will be no further parameterization options available. The chart shows the setting options for everey channel: ETS‐text Dynamic range comment [default value] not active Operating mode of the Channel A‐[O] Switch channels Staircase Table 9: Channel selection MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 15: Identical Parameter
The following illustration shows the setting options for this parameter: Figure 7: Operating mode The following chart shows the dynamic range for this parameter: ETS‐text Dynamic range comment [default value] Mode normally opened Relay operating mode of the normally closed channel Table 10: Operating mode The following diagram shows the behavior of the relay operating mode normally closed and normally opened. The input for the channels is a KNX‐telegram, which sends alternating 0‐signals and 1‐signals: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 16: Central Function
The following illustration shows the setting options at the ETS‐Software: Figure 9: Blocking function The following chart shows the dynamic range for this parameter: ETS‐text Dynamic range comment [default value] Behavior when locked On Behavior to a Behavior when unlocked Off blocking/unblocking process no change Table 13: Behavior at block/unblock MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 17 The following chart shows the corresponding communication object: Number Name Length Usage 2 Block 1 Bit blocks the channel Table 14: Communication object blocking function The following diagram describes the blocking process. For the “Behavior when locked”, the action on was parameterized and for the “Behavior when unlocked” the action off was parameterized: The KNX telegram shows which values are send to the blocking object. By sending a logical “1”, the blocking function is activated and the channel is switched on. The blocking function is deactivated again by sending a logical “0”. So the channel is switched off. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 18: Behavior At Bus Power Up/Down
Dynamic range comment [default value] Behavior at bus power up/ On Adjustment, how the channel Behavior at bus power down Off shall react in case of a bus no change power breakdown/return Table 15: Behavior at bus power up/down Every channel can occupy a certain state as well in case of a bus power breakdown as in case of a bus power return. The channel can be switched off or on, but also stay in its current state by choosing the parameter “no change”. To avoid problems in case of a bus power breakdown, you should adjust this parameter very conscientious. Because there is no controlling possible as long as the bus power is down. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 19: Manual Control And Cyclic Send Of The Current State
The setting “Send cyclic the current state value” activates the cyclic send of the state of the channel via its status object. The following chart shows the relevant communication objects: Number Name Length Usage 5 State 1 Bit Status object for the corresponding channel Manual control 1 Bit blocks the manual control in the channels with activated function Table 17: Communication objects manual control and cyclic send MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 20: Switching Output
Technical Manual Switch Actuators AMI/AMS 4.4 Switching output The following parameters, which are described at the headings 4.4.x, are only available at channels selected as switch. 4.4.1 Overview By choosing a channel as switch, a sub menu, called Channel A Switching, appears for this channel at the left drop down menu. The sub menu is shown at the following illustration: Figure 12: Switching output MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 21 with two objects And Logic operation Selection of the logic function Or only available, when the logic function was activated not active Scene Activation of the scene function active by activation this parameter a new sub menu appears (have a look at 4.4.4) Table 18: Switching output MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 22: On/Off Delay
Technical Manual Switch Actuators AMI/AMS 4.4.2 On/Off delay The following illustration shows the setting options at the ETS‐Software: Figure 13: On/Off delay The on‐delay causes a delayed switch of the channel. At sending an on‐signal to the channel, first the adjusted on delay time expires and afterwards the channel will be switched on. The off delay works on the same principle. At sending an off‐signal, first the adjusted off delay time expires and afterwards the channel will be switched off. Both functions work as well alone as combined. By adjusting “0 seconds” for a delay the function is switched off. The following diagram describes the combination of on and off delay: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 23: Logical Functions
Figure 15: Overview Logic function The logic function consists of the activated input objects and the switching object for each channel. The output of the logic is the respective relay output of the channel, so the physical switching of the channel. The following chart shows the relevant communication objects: Number Name Length Usage 6 Logic 1 1 Bit Logic object 1, is the first input for the logic block 7 Logic 2 1 Bit Logic object 2, is the second input for the logic block Table 19: Communication objects logic MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 24 0 1 Ja 1 1 0 Nein 1 1 0 Ja 1 1 1 Ja 1 1 1 Ja Table 20: Logic function MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 25: Scene Function
Figure 16: Scene function The following chart shows the relevant communication object: Number Name Length Usage 4 Scene 1 Byte Call of the scene Table 21: Communication object scene For calling a certain scene, you have to send the value for the scene to the communication object. The value of the scene number is always one number less than the adjusted scene number. For calling scene 1, you have to send a “0”. So the scene numbers have the numbers from 1 to 64, but the values for the scenes only from 0 to 63. If you want to call scenes by a binary input or another KNX device, you have to set the same number at the calling device as at the receiving device. The calling device, e.g. a binary input, sends automatically the right value for calling the scene. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 26 Technical Manual Switch Actuators AMI/AMS There are up to 8 storage options for scenes at every channel. These 8 storage options can get any of the possible 64 scene numbers. Figure 17: Sub function scene MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 27 Activation of the scene G On Scene number G 1‐64 Scene number; Calling value = 1 less [1] than the adjusted scene number Off Scene H Activation of the scene H On Scene number H 1‐64 Scene number; Calling value = 1 less [1] than the adjusted scene number Table 22: Parameter scene MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 28 0x1C 28 0x9C 156 30 0x1D 29 0x9D 157 31 0x1E 30 0x9E 158 32 0x1F 31 0x9F 159 Table 23: Calling and saving scenes MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 29 To note at the scene programming is that if you want to call 2 or more channels with the same scene number, you have to set the both communication objects for the scenes to the same group address. By sending the calling value, both scenes are called. Your programming can become much clearer if you divide your group addresses by scene numbers. If now one channel shall react to 8 scenes, you will have to connect the communication object for the scenes to 8 group addresses. The following illustrations shall make the division clearly: Figure 18: Programming of scenes The channels A and D shall react to the call of scene A and scene B. So they are connected to both group addresses. Furthermore you can save scenes at the according scene numbers. For that you have to activate the memory function at a channel of the switch actuator. Now you can call scenes by a binary input with a short keystroke and save scenes by a long keystroke. The adjusted value for the scene is overwritten by the current state of the actuator, when you save the scenes. At the next call of the scene, the scene will be called with the new value. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 30: Staircase
Technical Manual Switch Actuators AMI/AMS 4.5 Staircase The following parameters, which are described at the headings 4.5.x, are only available at channels selected as staircase. 4.5.1 Overview By choosing a channel as staircase, a sub menu, called Channel A Staircase, appears for this channel at the left drop down menu. The sub menu is shown at the following illustration: Figure 19: Staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 31 no change Off Behavior at bus power down Action for a bus power breakdown On no change Off Behavior at bus power up Action for a bus power return On no change Table 24: Parameter staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 32: Staircase Time
Figure 20: Staircase time The staircase function is activated by choosing a channel as staircase. This function enables an automatic turn off of the channel after an adjusted time, called “time for staircase”. The time for staircase can be parameterized freely. By sending an “on‐signal” at the communication object, the channel is switched on and the time runs out. After the time is ran out, the channel is switched off automatically. There are a lot of further functions to adjust the staircase function. These functions are described at the following segments. The following chart shows the relevant communication object: Number Name Length Usage 1 Staircase 1 Bit Calling of the staircase function Table 25: Communication object staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 33: Prewarning Und Warning
Technical Manual Switch Actuators AMI/AMS 4.5.3 Prewarning und Warning The following illustration shows the setting options at the ETS‐Software: Figure 21: Warning timer & prewarning time The warning function can be activated by adjusting the parameter “Prewarning” as active. Now, you can adjust warning time and prewarning time. The warning function is for warning that the staircase time ran almost out and the lights are switched off soon. This warning happens trough a short turn off the lights. The duration of the turn off is indicated by the warning time. A value of 1‐3s is advisable for this parameter. When the warning time runs out, the lights will be switched on again for the adjusted prewarning time. Now you have the opportunities to extend the staircase time, when this parameter was activated, or leave the staircase. A dynamic programming is advisable for this time. So you can adapt this time to spatial conditions (next switch, length of the staircase, etc.). The whole duration of the switching process is the sum of the 3 times. The following diagram shall make this clear: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 34: Manual Switch Off
4.5.4 Manual switch off The following illustration shows the setting options at the ETS‐Software: Figure 22: Manual switch off By activation this function, you can switch the channel off before the staircase time runs out. For switching off the channel, you have to send a logical “0” to the communication object for switching the staircase function (have a look at chart 20, page 27). When this function is not activated, the channel switches only off after the staircase time runs out. 4.5.5 Extend staircase time The following illustration shows the setting options at the ETS‐Software: Figure 23: Extend staircase time By activating this function, the staircase time is retriggerable. That means, when the staircase time runs already out to 2/3, you can restart the time by sending a new on‐signal to the communication object of the staircase function (have a look at chart 20, page 27). The following diagram shows the behavior of this parameter: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 35: Current Measurement
[not active] sending of the current value at determined changes not active Cyclic sending Activation and adjustment of the 15min sending of the current value at 30min determined times 60min 90min 120min Table 26: General settings current measurement MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 36 Figure 26: Calculation of the theoretical power The power of the channel is approximated calculated afterwards by a multiplication. Furthermore can be set, whether the channel shall be integrated to the total current measurement of the actuator (have a look at 4.6.2 Total current measurement). Also the sending conditions of the channel can be adjusted. The channel can send its actual value as well as determined percentage change or in fixed time steps, independent of a change of the value. Both sending conditions can be combined, too. The following chart shows the communication object for the current value: Number Name Length Usage 11 Current value 2/4 Byte sends the actual current value of the channel Table 27: Communication object current measurement MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 37: Power Meter Function
Via the object “Reset power meter”, the power meter can be set to zero again. So the power meter function offers an effective method for observing the power consumption of devices at determined cycles (day, week, month). An additional visualization of the power consumption can help saving energy and switch devices on demand. The following chart shows the relevant communication objects: Number Name Length Usage 15 Reset power meter 1 Bit resets the power meter to zero again 16 Active energy 4 Byte sends the measured energy Table 28: Communication object meter MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 38: Total Current Measurement
30min determined times 60min 90min 120min not active Monitoring exceedance of load Activation of the observation of the active exceedance of the load, have a look at 4.6.3 Monitoring exceedance/deviation of load Table 29: Total current MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 39: Total Power Meter Function
only request Sending object value Setting, whether the value shall be sent send cyclic 10min/ 30min/ cyclic or only on request 1h/ 3h/ 6h/ 12h/ 24h No Delete memory of all power Setting if all power meters shall be Yes meters after download of deleted or saved at a download application Table 31: Total power meter function MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 40: Monitoring Exceedance/Deviation Of Load
The communication object for the total power meter function is shown at the following chart: Number Name Length Usage Total active energy 4 Byte sends the summed up active energy Table 32: Communication object total power meter 4.6.5 Monitoring exceedance/deviation of load An observation of the load can be activated for every channel for an exceedance of a comparable worth as well as for a deviation of this worth. The total current measurement can only observe a exceedance. The possible settings are shown at the following illustration: Figure 31: Monitoring exceedance/deviation of load MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 41 At the deviation of load, a value is sent at deviating 1A, which only is reset when the value exceeds above 1,1A. The sending conditions of the according communication object can also be adjusted. The telegram can send as well on‐telegrams as off‐telegram for the different cases. Additional the object can sent no telegram. Also, a cyclic sending can be activated. The following chart shows the relevant communication objects: Number Name Length Usage 12 Exceedance of load 1 Bit reports an exceedance of load 13 Lower deviation of load 1 Bit reports an deviation of load Table 34: Communication objects load deviation/exceedance MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 42: Fault Current/ Load Failure
The following chart shows the relevant communication objects, which changes depending to the actual setting: Number Name Length Usage 14 Load faulty 1 Bit reports a load failure 14 Fault current 1 Bit reports a fault current 14 Fault current/Load faulty 1 Bit reports a fault current and a load failure Table 36: Communication object Fault current/Load faulty MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 43: Operating Hours
Furthermore can be adjusted when the communication object “Response operating hours” shall send a value. This function can be deactivated by the setting 0h. So the object is switched passive and sends no value, but can be requested. Via the object “Reset operating hours” the operating hours are set back to 0h. The following chart shows the relevant communication objects for this parameter: Number Name Length Usage 8 Response operating hours 2 Byte sends the number of counted operating hours 9 Reset operating hours 1 Bit sets the operating hours back to 0h Table 38: Communication object operating hours counter MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 44: Reverse Counter
Adjustment when a message shall be every … [h] [0h] sent Send signal of service 0‐250 Adjustment when a service is required at …x10h intervals [0h] Table 39: Reverse counter to next service The reverse counter to the next service can count the operating hours in which the channel is active. These can be counted back as well when the channel is switched on as when a determined current value is exceeded. The value when a service is required can be adjusted with the setting “Send signal of service at”. When this service time runs out, the dependent communication object “Service required” sends a service requirement. The setting 0h deactivates this function and so also the one described below. Via the setting “Send status of service hours every … h” can be adjusted in which steps the object “Time to next service” sends a message with the remaining operating hours before the next service. The setting 0h deactivates this function. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 45 Number Name Length Usage 8 Time to the next service 2 Byte sends the remaining time to the next service 9 Reset service 1 Bit resets service time back to the adjusted value 10 Service required 1 Bit reports that a service is required Table 40: Communication object reverse counter to next service MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 46: Index
Figure 26: Calculation of the theoretical power ................... 36 Figure 27: Power meter function ...................... 37 Figure 28: Settings power meter function .................... 37 Figure 29: Total current ......................... 38 Figure 30: Total power meter function .................... 39 Figure 31: Monitoring exceedance/deviation of load ................ 40 Figure 32: Error message ........................ 42 Figure 33: Operating hours counter ...................... 43 Figure 34: Reverse counter to next service ................... 44 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 47: List Of Tables
Table 28: Communication object meter .................... 37 Table 29: Total current .......................... 38 Table 30: Communication object total current .................. 39 Table 31: Total power meter function .................... 39 Table 32: Communication object total power meter ................ 40 Table 33: Monitoring exceedance/deviation of load ................ 41 Table 34: Communication objects load deviation/exceedance ............ 41 Table 35: Fault current/Load faulty ....................... 42 Table 36: Communication object Fault current/Load faulty .............. 42 Table 37: Operating hours counter ....................... 43 Table 38: Communication object operating hours counter .............. 43 Table 39: Reverse counter to next service .................... 44 Table 40: Communication object reverse counter to next service ............ 45 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 48: 6 Attachment
The above‐described devices must not be used with devices, which serve directly or indirectly the purpose of human, health‐ or lifesaving. Further the devices must not be used if their usage can occur danger for humans, animals or material assets. Do not let the packaging lying around careless, plastic foil/ ‐bags etc. can be a dangerous toy for kids. 6.2 Routine disposal Do not throw the waste equipment in the household rubbish. The device contains electrical devices, which must be disposed as electronic scrap. The casing contains of recyclable synthetic material. 6.3 Assemblage Risk for life of electrical power! All activities on the device should only be done by an electrical specialist. The county specific regulations and the applicable EIB‐directives have to be observed. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 49: Group State
active/inactive 0000 0000 0000 0000 0000 1111 1111 1111 0000 0101 0000 0101 0000 0000 1111 1111 ON/OFF 0000 0000 0000 0000 0000 1111 1111 1111 0000 0101 0000 0001 0000 0000 1101 1101 Output of the 00 00 00 00 0F FF 0F FF 05 05 05 01 00 FF 00 DD group state MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 50 The MDT Switch Actuator is a modular installation device for fixed installation in dry rooms. It fits on DIN 35mm rails in power distribution boards or closed compact boxes. The MDT Switch Actuator has a separate power supply terminals for each channel.
- Page 51 MDT Switch Actuator AMS/AMI AMS-0416.01 AMI-0416.01 Technical Data AMS-0816.01 AMI-0816.01 ( valid from hardware revision 2.0 ) AMS-1216.01 AMI-1216.01 Number of outputs Current measurement range 10mA - 20A 10mA - 20A Measuring inaccuracy Sampling rate 2000 samples/500ms 2000 samples/500ms Output switching ratings...
