MDT Glass Push Button II Smart Series Technical Manual page 37

Technical Manual Glass Push Button II Smart BE-GT2xx.01
Messages/Alarms
The following figure shows the available settings for messages and alarms:
Figure 9: Settings: Messages / Alarms
The following table shows the settings for the messages and alarms:
ETS-Text
Message 1-4 (Bit Objekt)
Text
Display time
Message text (14 Byte Object)
Display time
Cancel the messge (only for
hardware from version R1.5)
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
37
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
not active
active
any text (max. 14 characters)
not active
Until key is pressed
1s-8h
not active
active
not active
Until key is pressed
1s-8h
Over the end of display
time or push of button
Over the value 0 at
o je ts Message 1-4
Comment
Activation of message 1-4;
Message 1 (highest priority),
Message 4 (lowest priority)
Displayed text when the
message is triggered
Setting how long the message
should be displayed
Activation of the message text
via the 14 byte object; Message
text has the lowest priority of
all messages
Setting how long the message
should be displayed
Setting when the message
should be taken back
