Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.3 Push button functions

For each button function a block object as well as a function name can be defined. The block object
inhibits the operation of the button on receipt of a logic 1 and releases it again as soon as a logical 0
is received.
The function name is shown centric above the respective function and can be set steadily ("over text
input") or dynamically ("from message or state text) via communication object.
Identical parameters for all button functions are:
ETS-Text
Function name
Text
Blocking object
Table 22: Identical Parameters - Push button functions
Communication objects
The following table shows the available communication objects for the identical objects:
Number Name
4 Blocking object
Table 23: Identical objects - Push button functions
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
46
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
no text
from „message-te t
(14 Byte object 119)
from „"tate obje t
(14 Byte object 120)
fro „"tate o je t
(14 Byte object 121)
over text input
free text with up to 20
characters
not active
active
Length Usage
1 Bit Blocks the button function
Comment
Sets the data source for the
function name
Input of the function name;
Parameter is displayed if
function name is set via text
input
Activation/deactivation of the
block object for this button
function
