Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.1.2 Display Settings

Display appearance
The following settings can be used to customize the appearance of the display:
Figure 4: Settings: Display appearance
The following table shows the possible settings:
ETS-Text
Background color
Font size in function name
Font size for labeling of push
buttons
Behavior if the text is too long
Table 8: Display appearance
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
28
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
Day = black;
Night = black
Day = white;
Night = black
Day = black;
Night = white
Day = white;
Night = white
small
big
small
big
Text is clipped
Text size is reduced
Comment
Sets the background color of
the display
Sets the font size for the
function name
Setting the font size for the
button labeling
Setting of the behavior when
the text can not be displayed
completely
