Send Values; Switching Values/Scenes (Up To 4 Values) - MDT Glass Push Button II Smart Series Technical Manual

Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.3.2 Send values

4.3.2.1 Switching values/scenes (up to 4 values)

Single-button function
Two-button function
With the function "e d alues – - Switching values/scenes (up to 4 values) can be switched
between up to 4 different values of one data point type.
The following figure shows the available settings:
Figure 23: Settings: Send values - switching values/scenes (up to 4 values)
