12/2014
Technical Manual
MDT Switch Actuator
Series AKI:
AKI-0416.01
AKI-0816.01
AKI-1216.01
Series AKS:
AKS-0416.01 (until Q3 - 2012)
AKS-0410.01 (until Q3 - 2012)
AKS-0816.01 (until Q3 - 2012)
AKS-0810.01 (until Q3 - 2012)
AKS-1216.01 (until Q3 - 2012)
AKS-1210.01 (until Q3 - 2012)
AKS-0416.02 (from Q3 - 2012)
AKS-0816.02 (from Q3 - 2012)
AKS-1216.02 (from Q3 - 2012)
AKS-2016.02 (from Q3 - 2012)
Series AKK:
AKK-0810A.01
AKK-01UP.01
AKK-02UP.01
AKK-0216.01 (until Q2 – 2014)
AKK-0406.01 (until Q2 – 2014)
AKK-0816.01 (until Q2 – 2014)
AKK-0810.01 (until Q2 – 2014)
AKK-1616.01 (until Q2 – 2014)
AKK-1610.01 (until Q2 – 2014)
AKK-0216.02 (from Q2 – 2014)
AKK-0416.02 (from Q2 – 2014)
AKK-0816.02 (from Q2 – 2014)
AKK-1616.02 (from Q2 – 2014)
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
1
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Advertisement
Table of Contents
Related Manuals for MDT AKI-0416.01
Summary of Contents for MDT AKI-0416.01
- Page 1 AKK-1610.01 (until Q2 – 2014) AKK-0216.02 (from Q2 – 2014) AKK-0416.02 (from Q2 – 2014) AKK-0816.02 (from Q2 – 2014) AKK-1616.02 (from Q2 – 2014) MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 2: Table Of Contents
4.4 Switching output ......................... 22 4.4.1 Overview ..........................22 4.4.2 On/Off delay ......................... 24 4.4.3 Logical functions ........................25 4.4.4 Scene function ........................27 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 3 6 Attachment ............................39 6.1 Statutory requirements ....................... 39 6.2 Routine disposal .......................... 39 6.3 Assemblage ..........................39 6.4 Datasheet ............................ 40 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 4: Overview
2.1.1 Industrial design AKI Old series (until Q3 - 2013): AKI-0416.01 Switch actuator 4-fold,4TE, 230V AC, 16 A, C-Load 200µF, industrial design AKI-0816.01 Switch actuator 8-fold,8TE, 230V AC, 16 A, C-Load 200µF, industrial design ... -
Page 5: Compact Design Akk
For detailed information have a look at the next segment, 2.2 Exemplary circuit diagrams, or at the datasheets of the new series. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 6: Exemplary Circuit Diagrams
Figure 1: Exemplary circuit diagram AKI-1216.01 (until R2.x) From Hardware R3.0 (supplied by bus voltage): Figure 2: Exemplary circuit diagram AKI-0816.02 (from R3.0) MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 7: Aks
Old series (supplied by supply voltage): Figure 3: Exemplary circuit diagram AKS-1216.01 New series (supplied by bus voltage): Figure 4: Exemplary circuit diagram AKS-0816.02 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 8: Akk
Old series (supplied by supply voltage): Figure 5: Exemplary circuit diagram AKK-1610.01 New series (supplied by bus voltage): Figure 6: Exemplary circuit diagram AKK-0816.02 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 9: Structure & Handling
The monostable relays fall back to their output state when the power breaks down or the parameterization is updated. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 10: Functions
(AND/ OR) Scenes scene function for up to 8 scenes per channel Status functions feedback function Table 1: Overview functional possibilities MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 11: Settings At The Ets-Software
Order number: addicted to the used type, e.g.: AKI-1216.01 2.6. Starting up After wiring, the allocation of the physical address and the parameterization of every channel follow: (1) Connect the interface with the bus, e.g. MDT USB interface (2) Switching the power supply (3) Set bus power up... -
Page 12: Communication Objects
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 13 „Value for state channel and sends the current Toggle of Push output state of the channel. Buttons MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 14 Logical functions and can be control used for switching the channel according to the adjusted logical setting. (= Additional function) Table 2: Communication Objects MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 15: Default Settings Of The Communication Objects
The flags allocates the function of the objects in the programming thereby stands C for communication, R for Read, W for write, T for transmit and U for update. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 16: Reference Ets-Parameter
[default value] Startup timeout 1-60s Time between an upload and the [1s] functional start of the device Table 4: General settings MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 17: Channel Selection
Dynamic range comment [default value] not active Operating mode of the Channel A-[T] Switch channels Staircase Table 5: Channel selection MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 18: Identical Parameter
The following diagram shows the behavior of the relay operating mode normally closed and normally opened. The input for the channels is a KNX-telegram, which sends alternating 0-signals and 1-signals: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 19: Central Function
[default value] Behavior when locked Behavior to a Behavior when unlocked blocking/unblocking process no change Table 9: Behavior at block/unblock MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 20 The blocking function is deactivated agai y se di g a logi al . “o the ha el is switched off. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 21: Behavior At Bus Power Up/Down
To avoid problems in case of a bus power breakdown, you should adjust this parameter very conscientious. Because there is no controlling possible as long as the bus power is down. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 22: Switching Output
By choosing a channel as switch, a sub menu, called Channel A Switching, appears for this channel at the left drop down menu. The sub menu is shown at the following illustration: Figure 14: Switching output MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 23 Activation of the scene function active by activation this parameter a new sub menu appears (have a look at 4.4.4) Table 12: Switching output MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 24: On/Off Delay
Both functions work as well alone as combined. By adjusting 0 seconds for a delay the function is switched off. The following diagram describes the combination of on and off delay: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 25: Logical Functions
Logic object 1, is the first input for the logic block Logic 2 1 Bit Logic object 2, is the second input for the logic block Table 13: Communication objects logic MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 26 Switch Logic 1 Logic 2 Channel On/Off switched? On/Off switched? Nein Nein Nein Nein Nein Nein Nein Nein Table 14: Logic function MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 27: Scene Function
The calling device, e.g. a binary input, sends automatically the right value for calling the scene. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 28 There are up to 8 storage options for scenes at every channel. These 8 storage options can get any of the possible 64 scene numbers. Figure 19: Sub function scene MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 29 On Scene number H 1-64 Scene number; Calling value = 1 less than the adjusted scene number Table 16: Parameter scene MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 30 0x18 0x98 0x19 0x99 0x1A 0x9A 0x1B 0x9B 0x1C 0x9C 0x1D 0x9D 0x1E 0x9E 0x1F 0x9F Table 17: Calling and saving scenes MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 31 At the next call of the scene, the scene will be called with the new value. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 32: Staircase
By choosing a channel as staircase, a sub menu, called Channel A Staircase, appears for this channel at the left drop down menu. The sub menu is shown at the following illustration: Figure 21: Staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 33 Off Behavior at bus power up Action for a bus power return On no change Table 18: Parameter staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 34: Staircase Time
The following chart shows the relevant communication object: Number Name Length Usage Staircase 1 Bit Calling of the staircase function Table 19: Communication object staircase MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 35: Prewarning Und Warning
(next switch, length of the staircase, etc.). The whole duration of the switching process is the sum of the 3 times. The following diagram shall make this clear: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 36: Manual Switch Off
(have a look at chart 20, page 27). The following diagram shows the behavior of this parameter: MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 37: Index
Figure 23: Warning timer & prewarning time ..................35 Figure 24: Manual switch off ......................... 36 Figure 25: Extend staircase time ......................36 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 38: List Of Tables
Table 16: Parameter scene ........................29 Table 17: Calling and saving scenes....................... 30 Table 18: Parameter staircase ....................... 33 Table 19: Communication object staircase ................... 34 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 39: Attachment
All activities on the device should only be done by an electrical specialist. The county specific regulations and the applicable EIB-directives have to be observed. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 40: Datasheet
Technical Manual Switch Actuators AKI/AKS/AKK 6.4 Datasheet MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 41 A green LED indicates the switching status of each channel. The MDT Switch Actuator is suitable for extreme high inrush currents and used for heavy loads (C-Load).
- Page 42 MDT Switch Actuator AKI Technical Data AKI-0416.01 AKI-0816.01 AKI-1216.01 Number of outputs Output switching ratings Ohmic load 16A/20A* 16A/20A* 16A/20A* Capacitive load max. 200uF at 16A max. 200uF at 16A max. 200uF at 16A Voltage 230VAC 230VAC 230VAC 600A/150µs 600A/150µs 600A/150µs...
- Page 43 The MDT Switch Actuator has separate power supply terminals for each channel and are very space saving by ideal form factor. The MDT Switch Actuator is a modular installation device for ixed installation in dry rooms. It its on DIN 35mm rails in power distribution boards or closed compact boxes.
- Page 44 MDT Switch Actuator AKS AKS-0416.02 AKS-0816.02 Technical Data AKS-1216.02 AKS-2016.02 Number of outputs Output switching ratings Ohmic load Capacitive load max. 140uF at 16A Voltage 230VAC 600A/150µs Maximum inrush current 250A/600µs Maximum load 3000W Incandescent lamps 3000W Halogen lamps 230V...
- Page 45 Switch Actuators use a common power supply terminal for four channels. This feature simpliies the wiring and increases clarity of the circuit. The MDT Switch Actuator AKK is a modular installation device for ixed installations in dry rooms. It its on DIN 35mm rails in power distribution boards or closed compact boxes.
- Page 46 MDT Switch Actuator Technical Data AKK-0216.02 AKK-0416.02 AKK-0816.02 AKK-1616.02 Number of outputs Output switching ratings* Ohmic load Capacitive load 21uF at 10A 21uF at 10A 21uF at 10A 21uF at 10A Voltage 230VAC 230VAC 230VAC 230VAC 80A/150µs 80A/150µs 80A/150µs 80A/150µs Maximum inrush current 40A/600µs...
