MDT Glass Push Button II Smart Series Technical Manual page 55

Technical Manual Glass Push Button II Smart BE-GT2xx.01
Principle of operation:
The function "switching values/scenes" can send up to 4 different values by shortly pressing a button.
The values are then switched one after the other. Depending on the set parameters, for example, at
a keystroke the second switching value is sent if the 1st switching value has been sent before or the
third switching value will be sent if the second switching value has been sent before....
Parameter Push utton long :
Additionally to a switch over at a short keystroke, a fixed value can be sent at a long keystroke.
st
For example, the 1
(independent of the last switching value) would always be sent with a long keystroke.
The setting "4th Switching value if previous was 1st value, otherwise 1st value " represents a toggle
function, which switches back and forth between the 1
value was sent last, the 4th changeover value is sent, for each other value the 1st switching value is
sent.
The setting "send 0" causes sending the value 0 to the switch object.The setting "On at second
object" or "Off at second object" shows another communication object for the long keystroke. The
fixed value On or Off is then sent to this object with the size 1 bit.
Parameter " it hing type :
Limit stop: When the switching type "limit stop" is activated, the 4
th
after the 4 switching value has been sent.
Overrun: When the switching type "overrun" is activated, the 1
th
the 4 switching value.
For the single- utto fu tio , the para eter is set per a tl to o erru .
Parameter Switchover considers status object :
If the status value is not taken into account during the changeover, the button memorizes the last
sent value and sends the next or previous value on the next actuation without observing whether
another value has been sent to the object in the meantime.
If the status value is taken into account during the changeover, the next keystroke will send the next
higher or the next lower shift value - with respect to the last received status value. Example: the 2nd
switching value is set to 40% and the 3rd switching value is set to 70%. Now, after a received status
value of 50%, the value 70% is sent at next keystroke if the next switching value is to be sent and the
value 40% if the previous switching value is to be sent.
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
55
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
th
-4 switching value can be sent. Thus, the selected fixed switching value
st th
and 4 switching values. If the 1st switching
th
switching value is sent again
st
switching value is sent again after
