MDT Glass Push Button II Smart Series Technical Manual page 26

Technical Manual Glass Push Button II Smart BE-GT2xx.01
No. Name
106 Day/Night
107 Presence
108 Temperature
109 Temperature
110 Message
111 Message
112 Time
114 Time/Date
115 – Message 1-4
118 (Message 1 hightest
priority)
119 Message text
(lowest priority)
120 State text 1
121 State text 2
122 – State value 1-3
124
125 In operation
126 Push button
operation*
Table 6: Communication objects - Default settings common objects
* Object available in Glass Push Button II Smart without temperature from R1.2, in Glass Push
Buttpm II Smart with temperature from R1.0!
The preset default settings can be taken from the tables above. The priority of the individual
communication objects as well as the flags can be adapted as required by the user. The flags assign
the respective task to the communication objects in the programming. C stands for communication,
R for reading, W for writing, T for transmission, and U for updating.
