Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.4.2 LED 1-12/A/B

The following figure shows the available settings for each of the active LEDs:
Figure 44: Settings - LED 1-12/A/B
The table below shows all available settings:
ETS-Text
LED reacts to
Selection of object number
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
84
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
external object
internal object
button activation
external object and
button activation
internal object and
button activation
any object
Comment
Setting how LED is to be
controlled
Parameters only available when
LED reacts to internal object;
Link to internal object
