Danfoss VLT Automation Drive FC 360 Programming Manual page 129

Parameter Lists
5.2.4 3-** Reference/Ramps
Par. No. # Parameter description
3-0* Reference Limits
3-00 Reference Range
3-01 Reference/Feedback Unit
3-02 Minimum Reference
3-03 Maximum Reference
3-04 Reference Function
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-12 Catch up/slow Down Value
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
3-18 Relative Scaling Reference Resource
3-4* Ramp 1
3-40 Ramp 1 Type
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-5* Ramp 2
3-50 Ramp 2 Type
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-6* Ramp 3
3-60 Ramp 3 Type
3-61 Ramp 3 Ramp up Time
3-62 Ramp 3 Ramp down Time
3-7* Ramp 4
3-70 Ramp 4 Type
3-71 Ramp 4 Ramp up Time
3-72 Ramp 4 Ramp Down Time
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
3-9* Digital Pot.Meter
3-90 Step Size
3-92 Power Restore
3-93 Maximum Limit
3-94 Minimum Limit
3-95 Ramp Delay
MG06C602
Programming Guide
Default value
[0] Min - Max
ExpressionLimit
0 ReferenceFeedbackUnit
ExpressionLimit
[0] Sum
0%
5 Hz
0%
0%
[1] Analog Input 53
[2] Analog Input 54
[11] Local bus reference
[0] No function
[0] Linear
ExpressionLimit
ExpressionLimit
[0] Linear
ExpressionLimit
ExpressionLimit
[0] Linear
ExpressionLimit
ExpressionLimit
[0] Linear
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
0.10%
[0] Off
100%
-100%
1000 ms
Danfoss A/S © 7/2015 All rights reserved.
2-set-up Change Conversion
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
index
– Uint8
– Uint8
-3 Int32
-3 Int32
– Uint8
5
-2 Int16
-1 Uint16
-2 Int16
-2 Int16
– Uint8
– Uint8
– Uint8
–- Uint8
– Uint8
-2 Uint32
-2 Uint32
– Uint8
-2 Uint32
-2 Uint32
– Uint8
-2 Uint32
-2 Uint32
– Uint8
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint16
– Uint8
0 Int16
0 Int16
-3 Uint16
127
5
