Parameter Descriptions
6-72 Terminal 45 Digital Output
Option:
[82] SL digital output C
[83] SL digital output D
[160] No alarm
[161] Running reverse
[165] Local ref active
[166] Remote ref active
[167] Start command activ
[168] Drive in hand mode
[169] Drive in auto mode
[170] Homing Completed The homing operation is
completed. This option is only
effective when
parameter 37-00 Application Mode
is set to [2] Position Control.
[171] Target Position The target position is reached. This
Reached option is only effective when
parameter 37-00 Application Mode
is set to [2] Position Control.
[172] Position Control Fault A fault occurred in the positioning
process. Refer to
parameter 37-18 Pos. Ctrl Fault
Reason for details about the fault.
This option is only effective when
parameter 37-00 Application Mode
is set to [2] Position Control.
[173] Position Mech Brake Selects mechanical control for
positioning. This option is only
effective when
parameter 37-00 Application Mode
is set to [2] Position Control.
[174] TLD indicator Indicates whether the tension is
out of limit (on) during center
winding. This option is only
effective when
parameter 37-00 Application Mode
is set to [1] Center winder.
[175] Running on tension Indicates whether tension PID
control is active (on) or inactive
(off). This option is only effective
when parameter 37-00 Application
Mode is set to [1] Center winder.
[176] Ready to run The center winder control is ready
to run. This option is only effective
when parameter 37-00 Application
Mode is set to [1] Center winder.
[177] End of roll The diameter limit is reached. This
option is only effective when
parameter 37-00 Application Mode
is set to [1] Center winder.
MG06C602
Programming Guide
Function:
Danfoss A/S © 7/2015 All rights reserved.
6-72 Terminal 45 Digital Output
Option:
[193] Sleep Mode The frequency converter/system
has entered sleep mode. See
parameter group 22-4* Sleep Mode.
[194] Broken Belt Function A broken belt condition has been
detected. See parameter group
22-4* Sleep Mode.
[198] Drive Bypass
6-73 Terminal 45 Output Min Scale
Range: Function:
0 % [0 - Scale for the minimum output (0 or 4 mA) of
*
200 %] the analog signal at terminal 45. Set the value
to be the percentage of the full range of the
variable selected in parameter 6-71 Terminal 45
Analog Output.
6-74 Terminal 45 Output Max Scale
Range: Function:
100 % [0 - Scale for the maximum output (20 mA) of the
*
200 %] analog signal at terminal 45. Set the value to
be the percentage of the full range of the
variable selected in parameter 6-71 Terminal 45
Analog Output.
6-76 Terminal 45 Output Bus Control
Range: Function:
0 [0 - 16384 ] Holds the level of analog output if controlled
*
by bus.
4.7.5 6-9* Analog/Digital Output 42
Parameters for configuring the limits for analog/digital
output terminal 42. Analog outputs are current outputs:
0/4-20 mA. Resolution on analog outputs is 12 bit. Analog
output terminals can also be set up as digital output.
6-90 Terminal 42 Mode
Option: Function:
Set terminal 42 to act as analog output or
as digital output.
[0] 0-20 mA
*
[1] 4-20 mA
[2] Digital Output
6-91 Terminal 42 Analog Output
Option:
[0] No operation
*
[100] Output frequency
[101] Reference
[102] Process Feedback
[103] Motor Current
[104] Torque rel to limit
Function:
Function:
