Parameter Descriptions
8-43 PCD Read Configuration
Enter up to 16 different preset mapping (0-15) in this parameter,
using array programming. If this parameter is active, addresses
from 2910 to 2925 represent values of the 16 parameters. If this
parameter is not active, addresses 2910 and 2911 are used as
status word register and main actual value. Addresses from 2912
to 2925 are reserved.
Option:
[18] [1630] DC Link Voltage
[19] [1634] Heatsink Temp.
[20] [1635] Inverter Thermal
[21] [1638] SL Controller State
[22] [1650] External Reference
[23] [1652] Feedback [Unit]
[24] [1660] Digital Input 18,19,27,33
[25] [1661] Terminal 53 Switch
Setting
[26] [1662] Analog Input 53(V)
[27] [1663] Terminal 54 Switch
Setting
[28] [1664] Analog Input 54
[29] [1665] Analog Output 42 [mA]
[30] [1671] Relay Output [bin]
[31] [1672] Counter A
[32] [1673] Counter B
[33] [1690] Alarm Word
[34] [1692] Warning Word
[35] [1694] Ext. Status Word
[38] [1622] Torque [%]
4.9.5 8-5* Digital/Bus
Parameters for configuring the control word merging.
NOTICE
These parameters are active only when
parameter 8-01 Control Site is set to [0] Digital and control
word.
8-50 Coasting Select
Option: Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
[0] Digital Activates start command via a digital input.
input
[1] Bus Activates start command via the serial
communication port or fieldbus option.
[2] Logic AND Activates start command via the fieldbus/serial
communication port, and 1 extra digital input.
[3] Logic OR Activates start command via the fieldbus/serial
*
communication port, or via 1 of the digital
inputs.
MG06C602
Programming Guide
8-51 Quick Stop Select
Select control of the quick stop function via the terminals (digital
input) and/or via the bus.
Option:
[0]
[1]
[2]
Function:
[3]
*
8-52 DC Brake Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR Activates start command via the fieldbus/serial
*
8-53 Start Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
*
8-54 Reversing Select
Option:
[0] Digital
input
[1] Bus
Danfoss A/S © 7/2015 All rights reserved.
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
When parameter 1-10 Motor Construction
is set to [1] PM non-salient SPM, only
selection [0] Digital input is available.
Activates start command via a digital input.
Activates start command via the serial communi-
cation port or fieldbus option.
Activates start command via the fieldbus/serial
communication port, and additionally via 1 of
the digital inputs.
communication port, or via 1 of the digital
inputs.
Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
Activates a start command via a digital input.
Activates a start command via the serial
communication port or fieldbus option.
Activates a start command via the fieldbus/serial
communication port, and additionally via 1 of
the digital inputs.
Activates a start command via the fieldbus/serial
communication port, or via 1 of the digital
inputs.
Function:
Select control of the frequency converter reverse
function via the terminals (digital input) and/or
via the fieldbus.
Activates the reverse command via the serial
communication port or fieldbus option.
