Danfoss VLT Automation Drive FC 360 Programming Manual page 54

Table of Contents

Advertisement

Parameter Descriptions
5-14 Terminal 32 Digital Input
Option:
[82] Encoder input B
5-15 Terminal 33 Digital Input
Option:
[0]
No operation
*
4
4
[32] Pulse time based
[81] Enocder input A
5-16 Terminal 31 Digital Input
Option:
[0] No operation Functions are described in parameter group
4.6.3 5-3* Digital Outputs
The 2 solid-state digital outputs are common for terminals
27 and 29. Set the I/O function for terminal 27 in
parameter 5-01 Terminal 27 Mode, and set the I/O function
for terminal 29 in parameter 5-02 Terminal 29 Mode.
Terminals 42 and 45 can also be configured as digital
outputs.
NOTICE
These parameters cannot be adjusted while the motor is
running.
5-30 to 5-31 Digital Outputs
[0]
No operation
[1]
Control ready
[2]
Drive ready
[3]
Drive ready /
remote control
[4]
Enable / no
warning
[5]
Running
[6]
Running / no
warning
[7]
Run in range /
no warning
52
VLT
Function:
Function:
Functions are described in parameter
group 5-1* Digital Inputs.
Function:
5-1* Digital Inputs.
Default for all digital outputs and relay
outputs.
The control card is ready.
The frequency converter is ready for
operation and applies a supply signal on
the control board.
The frequency converter is ready for
operation and is in Auto On mode.
Ready for operation. No start or stop
command is given (start/disable). No
warnings are active.
The motor is running and shaft torque is
present.
The output speed is higher than the
speed set in parameter 1-81 Min Speed for
Function at Stop [RPM]. The motor is
running and there are no warnings.
The motor is running within the
programmed current and speed ranges
set in parameter 4-50 Warning Current Low
to parameter 4-51 Warning Current High.
There are no warnings.
Danfoss A/S © 7/2015 All rights reserved.
®
AutomationDrive FC 360
[8]
Run on
reference / no
warning
[9]
Alarm
[10]
Alarm or
warning
[11]
At torque limit
[12]
Out of current
range
[13]
Below current,
low
[14]
Above current,
high
[15]
Out of
frequency
range
[16]
Below
frequency, low
[17]
Above
frequency, high
[18]
Out of
feedback range
[19]
Below
feedback low
[20]
Above
feedback high
[21]
Thermal
warning
[22]
Ready, no
thermal
warning
[23]
Remote, ready,
no thermal
warning
[24]
Ready, no
overvoltage/
undervoltage
[25]
Reverse
[26]
Bus OK
[27]
Torque limit
and stop
The motor runs at reference speed. No
warnings.
An alarm activates the output. There are
no warnings.
An alarm or a warning activates the
output.
The torque limit set in
parameter 4-16 Torque Limit Motor Mode
or parameter 4-17 Torque Limit Generator
Mode has been exceeded.
The motor current is outside the range
set in parameter 4-18 Current Limit.
The motor current is lower than set in
parameter 4-50 Warning Current Low.
The motor current is higher than set in
parameter 4-51 Warning Current High.
Output frequency is outside the
frequency range.
The output speed is lower than the
setting in parameter 4-40 Warning Freq.
Low.
The output speed is higher than the
setting in parameter 4-41 Warning Freq.
High.
The feedback is outside the range set in
parameter 4-56 Warning Feedback Low and
parameter 4-57 Warning Feedback High.
The feedback is below the limit set in
parameter 4-56 Warning Feedback Low.
The feedback is above the limit set in
parameter 4-57 Warning Feedback High.
The thermal warning turns on when the
temperature exceeds the limit in the
motor, the frequency converter, the brake
resistor, or the thermistor.
The frequency converter is ready for
operation, and there is no overtem-
perature warning.
The frequency converter is ready for
operation and is in Auto On mode. There
is no overtemperature warning.
The frequency converter is ready for
operation and the mains voltage is within
the specified voltage range (see General
Specifications section in the design guide).
The motor runs (or is ready to run)
clockwise when logic=0 and counter-
clockwise when logic=1. The output
changes as soon as the reversing signal is
applied.
Active communication (no timeout) via
the serial communication port.
Use in performing a coast stop and in
torque limit condition. If the frequency
MG06C602
