Parameter Descriptions
4.15.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control
words.
16-80 Fieldbus CTW 1
Range: Function:
0 [0 - View the two-byte Control word (CTW) received
*
65535 ] from the Bus-Master. Interpretation of the CTW
depends on the fieldbus option installed and the
CTW profile selected in parameter 8-10 Control
Word Profile. For more information see relevant
fieldbus manuals.
16-82 Fieldbus REF 1
Range: Function:
0 [-32768 - View the two-byte word sent with the
*
32767 ] control word form the Bus-Master to set the
reference value. For more information please
refer to the relevant fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 [0 - 65535 ] View the extended fieldbus comm. option
*
status word. For more information, refer to the
relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
1084 [0 - View the two-byte Control word (CTW)
*
65535 ] received from the Bus-Master. Interpretation
of the Control word depends on the fieldbus
option installed and the Control word profile
selected in parameter 8-10 Control Word
Profile.
16-86 FC Port REF 1
Range: Function:
0 [-32768 - 32767 ] View the last received reference from the
*
FC port.
MG06C602
Programming Guide
4.15.7 16-9* Diagnosis Readouts
Use the parameters to display alarm, warning, and
extended status words.
16-90 Alarm Word
Range:
0 [0 - 0xFFFFFFFFUL ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] View the alarm word 2 sent via the
*
16-92 Warning Word
Range:
0 [0 - 0xFFFFFFFFUL ] View the warning word sent via the
*
16-93 Warning Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] View the warning word 2 sent via the
*
16-94 Ext. Status Word
Range:
0 [0 - 0xFFFFFFFFUL ] Returns the extended status word sent
*
16-95 Ext. Status Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] Returns the extended status word 2
*
Danfoss A/S © 7/2015 All rights reserved.
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
via the serial communication port in
hex code.
Function:
sent via the serial communication port
in hex code.
