Parameter Lists
5.2.16 17-** Feedback Options
Par. No. # Parameter description
17-1* Inc.Enc.Interface
17-10 Signal Type
17-11 Resolution (PPR)
17-5* Resolver Interface
17-50 Poles
5 5
17-51 Input Voltage
17-52 Input Frequency
17-53 Transformation Ratio
17-56 Encoder Sim. Resolution
17-59 Resolver Interface
17-6* Monitoring and App.
17-60 Feedback Direction
17-61 Feedback Signal Monitoring
5.2.17 18-** Data Readouts 2
Par. Parameter description
No. #
18-8* Center Winder Readout
18-81 Tension PID Output
18-82 Center Winder Output
18-83 Line Speed
18-84 Diameter
18-85 Tapered Tension Set Point
18-86 Tension Feedback
18-9* PID Readouts
18-90 Process PID Error
18-91 Process PID Output
18-92 Process PID Clamped Output
18-93 Process PID Gain Scaled Output
138
®
VLT AutomationDrive FC 360
Default value
[1] RS422 (5 V TTL)
1024 N/A
2 N/A
7 V
10 kHz
0.5 N/A
[0] Disabled
[0] Disabled
[0] Clockwise
[1] Warning
Default value
0 Hz
0 Hz
0 Hz
0%
0%
0%
0%
0%
0%
0%
Danfoss A/S © 7/2015 All rights reserved.
2-set-up Change Conversion
during
operation
All set-ups FALSE
All set-ups FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
4-set-up Change
during
operation
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
Type
index
– Uint8
0 Uint16
0 Uint8
-1 Uint8
2 Uint8
-1 Uint8
– Uint8
– Uint8
– Uint8
– Uint8
Conversion Type
index
-3 Int32
-3 Int32
-3 Int32
-3 Int32
-1 Int32
-1 Int32
-1 Int16
-1 Int16
-1 Int16
-1 Int16
