Parameter Lists
Par. No. # Parameter description
8-50 Coasting Select
8-51 Quick Stop Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
8-55 Set-up Select
8-56 Preset Reference Select
8-57 PROFIdrive OFF2 Select
5 5
8-58 PROFIdrive OFF3 Select
8-7* Protocol Firmware Version
8-79 Protocol Firmware version
8-8* FC Port Diagnostics
8-80 Bus Message Count
8-81 Bus Error Count
8-82 Slave Messages Rcvd
8-83 Slave Error Count
8-84 Slave Messages Sent
8-85 Slave Timeout Errors
8-88 Reset FC port Diagnostics
8-9* Bus Feedback
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
5.2.10 9-** PROFIdrive
Par. No. # Parameter description
9-00 Setpoint
9-07 Actual Value
9-15 PCD Write Configuration
9-16 PCD Read Configuration
9-18 Node Address
9-19 Drive Unit System Number
9-22 Telegram Selection
9-23 Parameters for Signals
9-27 Parameter Edit
9-28 Process Control
9-44 Fault Message Counter
9-45 Fault Code
9-47 Fault Number
9-52 Fault Situation Counter
9-53 PROFIBUS Warning Word
9-63 Actual Baud Rate
9-64 Device Identification
9-65 Profile Number
9-67 Control Word 1
9-68 Status Word 1
9-70 Programming Set-up
9-71 PROFIBUS Save Data Values
9-72 PROFIBUSDriveReset
132
®
VLT AutomationDrive FC 360
Default value
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
ExpressionLimit
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
[0] Do not reset
100 RPM
200 RPM
Default value
0 N/A
0 N/A
ExpressionLimit
ExpressionLimit
126 N/A
1037 N/A
[100] None
0
[1] Enabled
[1] Enable cyclic master
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
[255] No baudrate found
0 N/A
0 N/A
0 N/A
0 N/A
[9] Active Set-up
[0] Off
[0] No action
