Danfoss VLT Automation Drive FC 360 Programming Manual page 106

Parameter Descriptions
16-57 Feedback [RPM]
Range:
0 RPM [-30000 -
*
30000 RPM]
4 4
4.15.5 16-6* Inputs and Outputs
16-60 Digital Input
Range:
0 [0 -
*
65535 ]
16-61 Terminal 53 Setting
Option:
[0] Current mode
[1] Voltage mode
16-62 Analog Input 53
Range:
1 [0 - 20 ]
*
16-63 Terminal 54 Setting
Option:
[0] Current mode
[1] Voltage mode
16-64 Analog Input AI54
Range:
1 [0 - 20 ]
*
16-65 Analog Output 42 [mA]
Range:
0 mA [0 - 20
*
mA]
104
VLT
Function:
Readout parameter where the actual motor
RPM from the feedback source can be read
in both closed loop and open loop. The
feedback source is selected in
parameter 7-00 Speed PID Feedback Source.
Function:
View the actual state of the digital inputs 18,
19, 27 and 29.
Bit 0 Unused
Bit 1 Unused
Bit 2 Digital input term. 29
Bit 3 Digital input term. 27
Bit 4 Digital input term. 19
Bit 5 Digital input term. 18
Bit 6-15 Unused
Table 4.9 Bits Definition
Function:
View the setting of input terminal 53.
Function:
View the actual value at input 53.
Function:
View the setting of input terminal 54.
Function:
View the actual value at input 54.
Function:
View the actual value at output 42. The
value shown reflects the selections in
parameter 6-90 Terminal 42 Mode and
parameter 6-91 Terminal 42 Analog Output.
Danfoss A/S © 7/2015 All rights reserved.
®
AutomationDrive FC 360
16-66 Digital Output
Range:
0 [0 - 15 ]
*
16-67 Pulse Input #29 [Hz]
Range:
0 [0 - 130000 ] View the actual frequency rate on terminal 29.
*
16-68 Pulse Input 33 [Hz]
Range:
0 [0 - 130000 ] View the actual value of the frequency
*
16-69 Pulse Output 27 [Hz]
Range:
0 [0 - 40000 ] View the actual value of impulses applied to
*
16-70 Pulse Output 29 [Hz]
Range:
0 [0 - 40000 ] View the actual value of pulses to terminal 29
*
16-71 Relay Output
Range:
0 [0 - 65535 ]
*
16-72 Counter A
Range:
0 [-32768 -
*
32767 ]
16-73 Counter B
Range:
0 [-32768 -
*
32767 ]
16-79 Analog Output AO45
Range:
0 mA [0 - 20
*
mA]
Function:
View the binary value of all digital outputs.
Function:
Function:
applied at terminal 33 as an impulse input.
Function:
terminal 27 in digital output mode.
Function:
in digital output mode.
Function:
View the settings of all relays.
Function:
View the present value of counter A. Counters are
useful as comparator operands, see
parameter 13-10 Comparator Operand.
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital
Inputs), or by using an SLC action
(parameter 13-52 SL Controller Action).
Function:
View the present value of counter B. Counters are
useful as comparator operands
(parameter 13-10 Comparator Operand).
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital
Inputs) or by using an SLC action
(parameter 13-52 SL Controller Action).
Function:
View the actual value at output 45 in mA.
The value shown reflects the selection in
parameter 6-70 Terminal 45 Mode and
parameter 6-71 Terminal 45 Analog Output.
MG06C602
