Parameter Descriptions
1-16 High Speed Filter Time Const.
Range: Function:
is too short, the control becomes
unstable.
1-17 Voltage filter time const.
Range: Function:
Size [ 0.01 - 1 Reduces the influence of high
related s] frequency ripple and system resonance
*
in the calculation of supply voltage.
Without this filter, the ripples in the
currents can distort the calculated
voltage and affect the stability of the
system.
4.2.3 1-2* Motor Data
This parameter group comprises input data from the
nameplate on the connected motor.
NOTICE
Changing the value of these parameters affects the
setting of other parameters.
1-20 Motor Power
Option:
[2] 0.12 kW - 0.16 hp
[3] 0.18 kW - 0.25 hp
[4] 0.25 kW - 0.33 hp
[5] 0.37 kW - 0.5 hp
[6] 0.55 kW - 0.75 hp
[7] 0.75 kW - 1 hp
[8] 1.1 kW - 1.5 hp
[9] 1.5 kW - 2 hp
[10] 2.2 kW - 3 hp
[11] 3 kW - 4 hp
[12] 3.7 kW - 5 hp
[13] 4 kW - 5.4 hp
[14] 5.5 kW - 7.5 hp
[15] 7.5 kW - 10 hp
[16] 11 kW - 15 hp
[17] 15 kW - 20 hp
[18] 18.5 kW - 25 hp
[19] 22 kW - 30 hp
[20] 30 kW - 40 hp
[21] 37 kW - 50 hp
[22] 45 kW - 60 hp
[23] 55 kW - 75 hp
[24] 75 kW - 100 hp
[25] 90 kW - 120 hp
[26] 110 kW - 150 hp
MG06C602
Programming Guide
1-22 Motor Voltage
Range:
Size
related
1-23 Motor Frequency
Range:
Size
related
1-24 Motor Current
Range:
Size
related
Function:
1-25 Motor Nominal Speed
Range:
Size related
1-26 Motor Cont. Rated Torque
Range:
Size
related
Danfoss A/S © 7/2015 All rights reserved.
Function:
[50 - 1000 Enter the nominal motor voltage
V] according to the motor nameplate
*
data. The default value corresponds to
the nominal rated output of the unit.
Function:
NOTICE
This parameter cannot be changed
while the motor Is running.
[ 20 - Select the motor frequency value from the
500 motor nameplate. For 87 Hz operation with
*
Hz] 230/440 V motors, set the value according to
the nameplate data for 230 V/50 Hz. Adapt
parameter 4-14 Motor Speed High Limit [Hz] and
parameter 3-03 Maximum Reference to the 87
Hz application.
Function:
[ 0.01 - Enter the nominal motor current
10000.00 A] value from the motor nameplate
*
data. This data is used for
calculating motor torque, motor
thermal protection, and so on.
Function:
[50 - 60000 Enter the nominal motor speed
*
RPM] value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
Function:
[ 0.1 - Enter the value from the motor nameplate
10000 data. The default value corresponds to the
*
Nm] nominal rated output. This parameter is
available when parameter 1-10 Motor
Construction is set to [1] PM, non-salient
SPM, that is, the parameter is valid for PM
and non-salient SPM motors only.
4 4
