13-01 Start Event
Option:
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
4 4
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
*
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[83] Broken Belt
13-02 Stop Event
Option:
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
88
®
VLT AutomationDrive FC 360
13-02 Stop Event
Function: Option:
[34]
[35]
[36]
[39]
[40]
*
[42]
[50]
[51]
[60]
[61]
[70]
[71]
[72]
[73]
[74]
[83]
13-03 Reset SLC
Option:
[0]
*
[1]
Function:
4.12.2 13-1* Comparators
Comparators are used for comparing continuous variables
(that is output frequency, output current, analog input, and
so on.) to fixed preset values.
Par. 13-10
Comparator Operand
Par. 13-12
Comparator Value
Illustration 4.24 Comparators
There are digital values that are compared to fixed time
values. See explanation in parameter 13-10 Comparator
Operand. Comparators are evaluated once in each scan
interval. Use the result (true or false) directly. All
parameters in this parameter group are array parameters
with index 0 to 5. Select index 0 to program comparator 0,
select index 1 to program comparator 1, and so on.
Danfoss A/S © 7/2015 All rights reserved.
Digital input DI19
Digital input DI27
Digital input DI29
Start command
Drive stopped
Auto Reset Trip
Comparator 4
Comparator 5
Logic rule 4
Logic rule 5
SL Time-out 3
SL Time-out 4
SL Time-out 5
SL Time-out 6
SL Time-out 7
Broken Belt
Function:
Do not Retains programmed settings in
reset SLC chapter 4.12 Parameters: 13-** Smart Logic
Control.
Reset SLC Resets all parameters in
chapter 4.12 Parameters: 13-** Smart Logic
Control to default settings.
Par. 13-11
Comparator Operator
=
TRUE longer than.
. . .
. . .
