Parameter Lists
5.1.3 Active/Inactive Parameters in Different Drive Control Modes
+ indicates that the parameter is active in the mode.
- indicates that the parameter is inactive in the mode.
Parameter 1-10 Motor Construction
Parameter 1-01 Motor Control Principle
Parameter 1-00 Configuration Mode
[0] Speed Open Loop
[1] Speed Closed Loop
[3] Process
5 5
[4] Torque Open Loop
[6] Surface Winder
[7] Ext. PID Open Loop
Parameter 1-03 Torque Characteristics
Parameter 1-06 Clockwise Direction
Parameter 1-20 Motor Power [kW]
(parameter 0-03 Regional Settings =[0] International)
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
Parameter 1-29 Automatic Motor Adaptation (AMA)
Parameter 1-30 Stator Resistance (Rs)
Parameter 1-33 Stator Leakage Reactance (X1)
Parameter 1-34 Rotor Leakage Reactance (X2)
Parameter 1-35 Main Reactance (Xh)
Parameter 1-39 Motor Poles
Table 5.3 Active/Inactive Parameters
1) Constant torque
2) Variable torque
3) AEO
5) Used in flystart
Parameter 1-10 Motor Construction
Parameter 1-01 Motor Control Principle
Parameter 1-50 Motor Magnetisation at Zero Speed
Parameter 1-52 Min Speed Normal Magnetising [Hz]
Parameter 1-55 U/f Characteristic - U
Parameter 1-56 U/f Characteristic - F
Parameter 1-60 Low Speed Load Compensation
Parameter 1-61 High Speed Load Compensation
Parameter 1-62 Slip Compensation
Parameter 1-63 Slip Compensation Time Constant
Parameter 1-64 Resonance Damping
Parameter 1-65 Resonance Damping Time Constant
Parameter 1-71 Start Delay
Parameter 1-72 Start Function
Parameter 1-73 Flying Start
Parameter 1-75 Start Speed [Hz]
