Parameter Descriptions
[166] Remote ref
active
[167] Start command
active
[168] Drive in hand
mode
[169] Drive in auto
4 4
mode
[170] Homing
Completed
[171] Target Position
Reached
[172] Position
Control Fault
[173] Position Mech
Brake
[174] TLD indicator
[175] Running on
tension
[176] Ready to run
[177] End of roll
[193] Sleep mode
[194] Broken belt
5-30 Terminal 27 Digital Output
Option:
[0] No operation
*
[1] Control Ready
[2] Drive ready
54
®
VLT AutomationDrive FC 360
The output is high when there is an
active start command, and no stop
command is active.
The output is high when the frequency
converter is in Hand On mode.
The output is high when the frequency
converter is in Auto On mode.
The homing operation is completed. This
option is only effective
whenparameter 37-00 Application Mode is
set to [2] Position Control.
The target position is reached. This option
is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
A fault occurred in the positioning
process. Refer to parameter 37-18 Pos. Ctrl
Fault Reason for details about the fault.
This option is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
Selects mechanical control for positioning.
This option is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
Indicates whether the tension is out of
limit (on) during center winding. This
option is only effective when
parameter 37-00 Application Mode is set to
[1] Center winder.
Indicates whether tension PID control is
active (on) or inactive (off). This option is
only effective when
parameter 37-00 Application Mode is set to
[1] Center winder.
The center winder control is ready to run.
This option is only effective when
parameter 37-00 Application Mode is set to
[1] Center winder.
The diameter limit is reached. This option
is only effective when
parameter 37-00 Application Mode is set to
[1] Center winder.
The frequency converter/system has
entered sleep mode. See parameter group
22-4* Sleep Mode.
A broken belt condition has been
detected. See parameter group 22-4*
Sleep Mode.
Function:
Danfoss A/S © 7/2015 All rights reserved.
5-30 Terminal 27 Digital Output
Option:
[3] Drive rdy/rem ctrl
[4] Stand-by / no warning
[5] Running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of frequency range
[16] Below frequency, low
[17] Above frequency, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready, no thermal warning
[23] Remote,ready,no TW
[24] Ready, no over-/ under voltage
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake warning
[29] Brake ready, no fault
[30] Brake fault (IGBT)
[31] Relay 123
[32] Mech brake ctrl
[36] Control word bit 11
[37] Control word bit 12
[40] Out of ref range
[41] Below reference, low
[42] Above ref, high
[43] Extended PID Limit
[45] Bus ctrl.
[46] Bus control, timeout: On
[47] Bus control, timeout: Off
[55] Pulse output
[56] Heat sink cleaning warning, high
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
Function:
