Parameter Lists
5.2.24 37-** Application Settings
Par. No. # Parameter description
37-0* Application Mode
37-00 Application Mode
37-1* Position Control
37-01 Pos. Feedback Source
37-02 Pos. Target
37-03 Pos. Type
37-04 Pos. Velocity
5 5
37-05 Pos. Ramp Up Time
37-06 Pos. Ramp Down Time
37-07 Pos. Auto Brake Ctrl
37-08 Pos. Hold Delay
37-09 Pos. Coast Delay
37-10 Pos. Brake Delay
37-11 Pos. Brake Wear Limit
37-12 Pos. PID Anti Windup
37-13 Pos. PID Output Clamp
37-14 Pos. Ctrl. Source
37-15 Pos. Direction Block
37-16 Pos. Power Recovery
37-17 Pos. Ctrl Fault Behaviour
37-18 Pos. Ctrl Fault Reason
37-19 Pos. New Index
37-2* Center Winder1 set-up
37-20 Winder Mode Selection
37-21 Tension Set Point
37-22 Taper Set Point
37-23 Partial Roll Diameter Value
37-24 Core1 Diameter
37-25 Core2 Diameter
37-26 Winder Jog Speed
37-27 TLD Low Limit
37-28 TLD High Limit
37-29 TLD Timer
37-30 TLDOnDelay
37-31 Diameter Limit Detector
37-32 Initial Diameter Measurement
37-33 Diameter Measurement Input
37-34 Reading at Core
37-35 Reading at Full Roll
37-36 Tension Set Point Input
37-37 Taper Set Point Input
37-38 Tension Feedback Input
37-39 Tension Feedback Type
37-40 Center Winder Cmd Src
37-41 Diameter Change Rate
37-42 Tapered Tension Change Rate
142
®
VLT AutomationDrive FC 360
Default value
[0] Drive mode
[0] 24 V Encoder
0 N/A
[0] Absolute
100 RPM
5000 ms
5000 ms
[1] Enable
0 ms
200 ms
200 ms
0 N/A
[1] Enable
1000 N/A
[0] DI
[0] No Blocking
[1] Enable
[0] Ramp Down&Brake
[0] No Fault
0 N/A
[0] Wind
0%
0%
5%
5%
5%
0%
0%
0%
0.001 s
[1] Enabled
100%
[0] Set diameter when
diameter reset
[0] No Function
0 N/A
0 V
[0] Par.3721
[0] Par.3722
[0] No Function
[0] Load cell
[1] Parameter
3754~3759 control the
functions
0.001%
0.1%
Danfoss A/S © 7/2015 All rights reserved.
2-set-up Change during
operation
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
Conversion Type
index
– Uint8
– Uint8
0 Int32
– Uint8
67 Uint16
-3 Uint32
-3 Uint32
– Uint8
-3 Uint32
-3 Uint16
-3 Uint16
0 Uint32
– Uint8
0 Uint16
– Uint8
– Uint8
– Uint8
– Uint8
– Uint8
– Uint8
– Uint8
-1 Uint16
-1 Int16
-3 Uint32
-3 Uint32
-3 Uint32
0 Uint8
-1 Uint16
-1 Uint16
-3 Uint16
– Uint8
-3 Uint32
– Uint8
– Uint8
-2 Int16
-2 Int16
– Uint8
– Uint8
– Uint8
– Uint8
– Uint8
-3 Uint8
-1 Uint8
