Danfoss VLT Automation Drive FC 360 Programming Manual page 50

Parameter Descriptions
4-41 Warning Freq. High
Range:
4-42 Adjustable Temperature Warning
Range:
0 [ 0 - 255 ] Use this parameter to set the motor temperature
*
4 4
4.5.5 4-5* Adjustable Warnings
Use these parameters to adjust warning limits for current,
speed, reference, and feedback.
4-50 Warning Current Low
Range:
0 A [ 0 - 194.0
*
A]
4-51 Warning Current High
Range:
Size [ 0.0 -
related 194.0 A]
*
4-54 Warning Reference Low
Range:
-4999 [-4999 -
*
4999 ]
4-55 Warning Reference High
Range:
4999 [-4999 -
*
4999 ]
48
VLT
Function:
LCP warning light is not lit when the limit set
is reached.
Function:
limit.
Function:
Enter the I value. When the motor current
LOW
drops below this limit, a bit in the status word
is set. This value can also be programmed to
produce a signal on the digital output or the
relay output.
Function:
Enter the I value. When the motor
HIGH
current exceeds this limit, a bit in the
status word is set. This value can also be
programmed to produce a signal on the
digital output or the relay output.
Function:
Enter the low reference limit. When the actual
reference falls below this limit, the display
shows Ref . Bit 20 is set in
LOW
parameter 16-94 Ext. Status Word. The output
relay or the digital output can be configured
to indicate this warning. The LCP warning
light is not turned on when this parameter set
limit is reached.
Function:
Use this parameter to set a high limit for the
reference range. When the actual reference
exceeds this limit, the display shows Ref
19 is set in parameter 16-94 Ext. Status Word.
The output relay or the digital output can be
configured to indicate this warning. The LCP
warning light is not turned on when this
parameter set limit is reached.
Danfoss A/S © 7/2015 All rights reserved.
®
AutomationDrive FC 360
4-56 Warning Feedback Low
Range:
-4999
ProcessCtrlUnit
4-57 Warning Feedback High
Range:
4999
ProcessCtrlUnit
4-58 Missing Motor Phase Function
Option:
[0] Off No alarm is shown if a missing motor phase occurs.
[1] On An alarm is shown if a missing motor phase occurs.
*
4.5.6 4-6* Speed Bypass
4-61 Bypass Speed From [Hz]
Range:
0 Hz [ 0 - 500
*
Hz]
. Bit
HIGH
4-63 Bypass Speed To [Hz]
Range:
0 Hz [ 0 - 500
*
Hz]
Function:
[-4999 - 4999 Use this parameter to set a
ProcessCtrlUnit] low limit for the feedback
*
range. When the feedback
falls below this limit, the
display shows Feedb Low. Bit
6 is set in
parameter 16-94 Ext. Status
Word. The output relay or the
digital output can be
configured to indicate this
warning. The LCP warning
light is not turned on when
this parameter set limit is
reached.
Function:
[-4999 - 4999 Use this parameter to set a
ProcessCtrlUnit] high limit for the feedback
*
range. When the feedback
exceeds this limit, the display
reads Feedb High. Bit 5 is set
in parameter 16-94 Ext. Status
Word. The output relay or the
digital output can be
configured to indicate this
warning. The LCP warning
light is not turned on when
this parameter set limit is
reached.
Function:
Function:
Some systems call for avoiding certain
output speeds due to resonance problems
in the system. Enter the lower limits of the
speeds to be avoided.
Function:
Some systems call for avoiding certain
output speeds due to resonance problems
in the system. Enter the upper limits of the
speeds to be avoided.
MG06C602
