Parameter Descriptions
5-40 Function Relay
Option:
[193] Sleep Mode
4 4
[194] Broken Belt
Function
5-41 On Delay, Relay
Array [2](Relay 1 [0], Relay 2 [1])
Range:
0.01 s [0.01 - 600
*
s]
Selected
Event
Relay
output
Selected
Event
Relay
output
Illustration 4.12 On Delay, Relay
5-42 Off Delay, Relay
Array[2]: Relay1[0], Relay2[1]
Range:
0.01 s [0.01 - 600 s] Enter the delay of the relay cut-out time.
*
Selected
Event
Relay
output
Illustration 4.13 Off Delay, Relay
58
Function:
parameter 37-00 Application Mode is set
to [1] Center winder.
The frequency converter/system has
entered sleep mode. See parameter
group 22-4* Sleep Mode.
A broken belt condition has been
detected. See parameter group 22-4*
Sleep Mode.
Function:
Enter the delay of the relay cut-in time.
The relay only cuts in if the condition in
parameter 5-40 Function Relay is uninter-
rupted during the specified time.
On Delay O Delay
P 5-41
On Delay
P 5-41
Function:
On Delay O Delay
P 5-41 P 5-42
Danfoss A/S © 7/2015 All rights reserved.
®
VLT AutomationDrive FC 360
If the selected event condition changes before the on- or
off delay timer expires, the relay output is unaffected.
4.6.5 5-5* Pulse Input
The pulse input parameters are used to define an
appropriate window for the impulse reference area by
configuring the scaling and filter settings for the pulse
inputs. Input terminals 29 or 33 act as frequency reference
inputs. Set terminal 29 (parameter 5-13 Terminal 29 Digital
Input) or terminal 33 (parameter 5-15 Terminal 33 Digital
Input) to [32] Pulse input . If terminal 29 is used as an input,
then set parameter 5-01 Terminal 27 Mode to [0] Input.
Ref.
High
ref.
value
P 5-53/
p 5-58
Low
ref.
value
P 5-52/
p 5-57
Illustration 4.14 Pulse Input
P 5-42
5-50 Term. 29 Low Frequency
Range:
4 Hz
*
Hz]
5-51 Term. 29 High Frequency
Range:
32000
Hz
*
5-52 Term. 29 Low Ref./Feedb. Value
Range:
0 [-4999 -
*
4999 ]
Low freq.
P 5-50/
P 5-55
Function:
[4 - 31999 Enter the low frequency limit corresponding
to the low motor shaft speed (that is low
reference value) in parameter 5-52 Term. 29
Low Ref./Feedb. Value. Refer to the
Illustration 4.14 in this section.
Function:
[5 - 32000 Enter the high frequency limit
Hz] corresponding to the high motor shaft
speed (which is high reference value) in
parameter 5-53 Term. 29 High Ref./Feedb.
Value.
Function:
Enter the low reference value limit for the motor
shaft speed [Hz]. This value is also the lowest
feedback value, see also parameter 5-57 Term. 33
Low Ref./Feedb. Value. Set terminal 29 to digital
input (parameter 5-02 Terminal 29 Mode=[0] Input
and parameter 5-13 Terminal 29 Digital
Input=applicable value.
High freq. Input
P 5-51/ (Hz)
P 5-56
