Danfoss VLT Automation Drive FC 360 Programming Manual page 142

Parameter Lists
5.2.21 32-** Motion Control Basic Settings
Par. No. # Parameter description
32-11 User Unit Denominator
32-12 User Unit Numerator
32-67 Max. Tolerated Position Error
32-69 PID Sample Time
32-80 Maximum Allowed Velocity
32-81 Motion Ctrl Quick Stop Ramp
5 5
5.2.22 33-** Motion Control Adv. Settings
Par. No. # Parameter description
33-00 Force Home
33-01 Home Offset
33-02 Home Ramp Time
33-03 Homing Velocity
33-04 Homing Type
33-41 Negative Software Limit
33-42 Positive Software Limit
33-43 Negative Software Limit Active
33-44 Positive Software Limit Active
33-47 Target Position Window
140
®
VLT AutomationDrive FC 360
Default value
1 N/A
1 N/A
2000000 N/A
16 ms
1500 RPM
1000 ms
Default value
[0] Home not forced
0 N/A
10 ms
100 RPM
[1] Reverse no index
-500000 N/A
500000 N/A
[0] Inactive
[0] Inactive
0 N/A
Danfoss A/S © 7/2015 All rights reserved.
2-set-up Change during
operation
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up TRUE
2-set-up Change during
operation
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
Conversion Type
index
0 Uint32
0 Uint32
0 Uint32
-3 Uint16
67 Uint16
-3 Uint32
Conversion Type
index
– Uint8
0 Int32
-3 Uint16
67 Int16
– Uint8
0 Int32
0 Int32
– Uint8
– Uint8
0 Uint16
MG06C602
