Parameter Descriptions
4.9 Parameters: 8-** Communications and
Options
4.9.1 8-0* General Settings
8-01 Control Site
Option: Function:
The setting in this parameter overrides
the settings in parameter 8-50 Coasting
Select to parameter 8-56 Preset Reference
Select.
[0] Digital and Control by using both digital input and
*
ctrl.word control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword Control by using control word only.
only
8-02 Control Source
Option: Function:
Select the source of the control word.
NOTICE
This parameter cannot be adjusted while
the motor is running.
[0] None
[1] FC Port
[3] Option A PROFIBUS and PROFINET.
8-03 Control Timeout Time
Range: Function:
1 s [0.1 - Enter the maximum time expected to pass
*
6000 s] between the reception of 2 consecutive
telegerams. If this time is exceeded, it indicates
that the serial communication has stopped. The
function that is selected in
parameter 8-04 Control Timeout Function is then
carried out.
8-04 Control Timeout Function
Option: Function:
[0] Off Select the time-out function. The time-out
*
function is activated when the control word
fails to be updated within the time period
specified in parameter 8-03 Control Timeout
Time.
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
MG06C602
Programming Guide
8-07 Diagnosis Trigger
Option:
[0]
*
[1]
[2]
4.9.2 8-1* Ctrl. Word Settings
8-10 Control Word Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the installed fieldbus are visible in the LCP display.
Option:
[0]
*
[1]
8-14 Configurable Control Word CTW
Option:
[0]
[1]
*
[2]
[4]
[5]
[6]
8-19 Product Code
Range:
Size
related
*
4.9.3 8-3* FC Port Settings
8-30 Protocol
Option:
[0] FC
*
[2] Modbus RTU Communication according to the Modbus
8-31 Address
Range:
1 [ 0.0 - 247 ] Enter the address for the RS485 port. Valid
*
8-32 Baud Rate
Option:
[0] 2400 Baud
Danfoss A/S © 7/2015 All rights reserved.
Disable
Trigger on alarms
Trigger alarm/warn.
FC profile
PROFIdrive profile
None
Profile default
CTW Valid, active low
PID error inverse
PID reset I part
PID enable
Function:
[0 - Select 0 to read out the actual
2147483647] fieldbus product code according
to the mounted fieldbus option.
Select 1 to read out the actual
vendor ID.
Function:
Select the protocol for the integrated RS485
port.
Communication according to the FC Protocol.
RTU protocol.
Function:
range: 1-126 for FC-bus, or 1-247 for Modbus.
Function:
Select the baud rate for the RS485 port.
Function:
4
Function:
Function:
73
4
