Parameter Descriptions
[51]
External
This function makes it possible to give an
interlock
external fault to the frequency converter. This
fault is treated in the same way as an
internally generated alarm.
[60]
Counter A
(Terminal 29 or 33 only) Input for increment
counting in the SLC counter.
[61]
Counter A
(Terminal 29 or 33 only) Input for decrement
counting in the SLC counter.
[62]
Reset
Input for reset of counter A.
Counter A
[63]
Counter B
(Terminal 29 or 33 only) Input for increment
counting in the SLC counter.
[64]
Counter B
(Terminal 29 or 33 only) Input for decrement
counting in the SLC counter.
[65]
Reset
Input for reset of counter B.
Counter B
[72]
PID error
Inverts the resulting error from the process
inverse
PID controller. Available only if
parameter 1-00 Configuration Mode is set to [6]
Surface Winder or [7] Extended PID Speed OL.
[73]
PID reset I-
Resets the I-part of the process PID controller.
part
Equivalent to parameter 7-40 Process PID I-part
Reset. Available only when
parameter 1-00 Configuration Mode is set to [6]
Surface Winder or [7] Extended PID Speed OL.
[74]
PID enable This option enables the extended process PID
controller. Equivalent to parameter 7-50 Process
PID Extended PID. Available only if
parameter 1-00 Configuration Mode is set to [7]
Extended PID Speed OL.
[150] Go To
The frequency converter moves to the home
Home
position.
[151] Home Ref.
Indicates the status of the home referenced
Switch
switch. on means that the home position is
reached, off means that the home position is
not reached.
[155] HW Limit
The positive hardware position limit is
Positive
exceeded. This option is active on the falling
edge.
[156] HW Limit
The negative hardware position limit is
Negative
exceeded. This option is active on the falling
edge.
[157] Pos. Quick
Stops the frequency converter during
Stop Inv
positioning with the ramp time that is set in
parameter 32-81 Motion Ctrl Quick Stop Ramp.
This option is only effective when
parameter 37-00 Application Mode is set to [2]
Position Control.
[160] Go To
The frequency converter moves to the target
Target Pos.
position. This option is only effective when
parameter 37-00 Application Mode is set to [2]
Position Control.
[162] Pos. Idx
Position index bit 0. This option is only
Bit0
effective when parameter 37-00 Application
Mode is set to [2] Position Control.
MG06C602
Programming Guide
[163] Pos. Idx
Bit1
[164] Pos. Idx
Bit2
[165] Core
diameter
source
[166] New
diameter
select
[167] Reset
diameter
[168] Winder jog
forward
[169] Winder jog
reverse
[170] Tension on Enables tension PID control. This option is
5-10 Terminal 18 Digital Input
Option:
[8]
Start Functions are described in parameter group 5-1*
*
5-11 Terminal 19 Digital Input
Option:
[10]
Reversing Functions are described in parameter group
*
5-12 Terminal 27 Digital Input
Option:
[2]
Coast inverse Functions are described in parameter group
*
5-13 Terminal 29 Digital Input
Option:
[14]
Jog
*
[32]
Pulse time based
5-14 Terminal 32 Digital Input
Option:
[0]
No operation
*
Danfoss A/S © 7/2015 All rights reserved.
Position index bit 1. This option is only
effective when parameter 37-00 Application
Mode is set to [2] Position Control.
Position index bit 2. This option is only
effective when parameter 37-00 Application
Mode is set to [2] Position Control.
The core diameter source. off means core 1 is
selected, and on means that core 2 is
selected. This option is only effective when
parameter 37-00 Application Mode is set to [1]
Center winder.
Configures whether to select partial roll
diameter (off) or core diameter (on). This
option is only effective when
parameter 37-00 Application Mode is set to [1]
Center winder.
Resets the diameter. This option is only
effective when parameter 37-00 Application
Mode is set to [1] Center winder.
Enables jog forward during center winding.
This option is only effective when
parameter 37-00 Application Mode is set to [1]
Center winder.
Enables jog reverse during center winding.
This option is only effective when
parameter 37-00 Application Mode is set to [1]
Center winder.
only effective when
parameter 37-00 Application Mode is set to [1]
Center winder.
Function:
Digital Inputs.
Function:
5-1* Digital Inputs.
Function:
5-1* Digital Inputs.
Function:
Functions are described in parameter
group 5-1* Digital Inputs.
Function:
Functions are described in parameter
group 5-1* Digital Inputs.
4
4
51
