Danfoss VLT Automation Drive FC 360 Programming Manual page 139

Parameter Lists
Par. No. # Parameter description
16-57 Feedback [RPM]
16-6* Inputs & Outputs
16-60 Digital Input
16-61 Terminal 53 Setting
16-62 Analog Input 53
16-63 Terminal 54 Setting
16-64 Analog Input AI54
16-65 Analog Output 42 [mA]
16-66 Digital Output
16-67 Pulse Input 29[Hz]
16-68 Pulse Input 33 [Hz]
16-69 Pulse Output 27 [Hz]
16-70 Pulse Output 29 [Hz]
16-71 Relay Output
16-72 Counter A
16-73 Counter B
16-79 Analog Output AO45
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm. Option STW
16-85 FC Port CTW 1
16-86 FC Port REF 1
16-9* Diagnosis Readouts
16-90 Alarm Word
16-91 Alarm Word 2
16-92 Warning Word
16-93 Warning Word 2
16-94 Ext. Status Word
16-95 Ext. Status Word 2
16-97 Alarm Word 3
MG06C602
Programming Guide
Default value
0 RPM
0 N/A
ExpressionLimit
1 N/A
ExpressionLimit
1 N/A
0 mA
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 mA
0 N/A
0 N/A
0 N/A
1084 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
Danfoss A/S © 7/2015 All rights reserved.
2-set-up Change Conversion
during
operation
All set-ups FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
Type
index
67 Int32
0 Uint16
– Uint8
-2 Uint16
– Uint8
-2 Uint16
-2 Uint16
5
0 VisStr[5]
0 Int32
0 Int32
0 Int32
0 Int32
0 Uint16
0 Int16
0 Int16
-2 Uint16
0 Uint16
0 Int16
0 Uint16
0 uint16
0 Int16
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Uint32
137
5
