Danfoss VLT Automation Drive FC 360 Programming Manual page 45

Parameter Descriptions
3-41 Ramp 1 Ramp Up Time
Range: Function:
Size [0.05 - Enter the ramp-up time, that is the
related 3600 s] acceleration time from 0 RPM to the
*
synchronous motor speed n
up time such that the output current does
not exceed the current limit in
parameter 4-18 Current Limit during ramping.
The value 0.00 corresponds to 0.01 s in
speed mode. See ramp-down time in
parameter 3-42 Ramp 1 Ramp Down Time.
Par . 3 − 41 =
3-42 Ramp 1 Ramp Down Time
Range: Function:
Size [0.05 - Enter the ramp-down time, that is, the
related 3600 s] deceleration time from the synchronous
*
motor speed n
down time such that no overvoltage occurs
in the inverter due to regenerative operation
of the motor, and such that the generated
current does not exceed the current limit set
in parameter 4-18 Current Limit. The value
0.00 corresponds to 0.01 s in speed mode.
See ramp-up time in parameter 3-41 Ramp 1
Ramp Up Time.
Par . 3 − 42 =
4.4.4 3-5* Ramp 2
This parameter group configures ramp 2 parameters.
3-50 Ramp 2 Type
Option: Function:
Select the ramp type, depending on
requirements for acceleration/deceleration. A
linear ramp gives constant acceleration during
ramping. A sine 2 ramp gives non-linear
acceleration.
[0] Linear
*
[2] Sine 2 S-ramp based on the values set in
Ramp parameter 3-41 Ramp 1 Ramp Up Time and
parameter 3-42 Ramp 1 Ramp Down Time.
3-51 Ramp 2 Ramp Up Time
Range: Function:
Size [0.05 - Enter the ramp-up time, which is the
related 3600 s] acceleration time from 0 RPM to the rated
*
motor speed n
that the output current does not exceed the
current limit in parameter 4-18 Current Limit
during ramping. The value 0.00 corresponds
to 0.01 s in speed mode. See ramp-down
MG06C602
Programming Guide
. Select a ramp-
S
t s x n RPM
acc s
ref RPM
to 0 RPM. Select a ramp-
s
t s x n RPM
dec s
ref RPM
. Select a ramp-up time such
s
Danfoss A/S © 7/2015 All rights reserved.
3-51 Ramp 2 Ramp Up Time
Range: Function:
time in parameter 3-52 Ramp 2 Ramp Down
Time.
Par . 3 − 51 =
3-52 Ramp 2 Ramp Down Time
Range:
Size related [0.05 - 3600 s]
*
4.4.5 3-6* Ramp 3
This parameter group configures ramp 3 parameters.
3-60 Ramp 3 Type
Option: Function:
Select the ramp type, depending on
requirements for acceleration/deceleration. A
linear ramp gives constant acceleration during
ramping. An S-ramp gives non-linear
acceleration.
[0] Linear
*
[2] Sine 2 S-ramp based on the values set in
Ramp parameter 3-61 Ramp 3 Ramp up Time and
parameter 3-62 Ramp 3 Ramp down Time.
3-61 Ramp 3 Ramp up Time
Range: Function:
Size [0.05 - Enter the ramp-up time, which is the
related 3600 s] acceleration time from 0 RPM to the rated
*
motor speed n
that the output current does not exceed the
current limit in parameter 4-18 Current Limit
during ramping. The value 0.00 corresponds
to 0.01 s in speed mode. See ramp-down
time in parameter 3-62 Ramp 3 Ramp down
Time.
3-62 Ramp 3 Ramp down Time
Range: Function:
Size [0.05 - Enter the ramp-down time, which is the
related 3600 s] deceleration time from the rated motor
*
speed n to 0 RPM. Select a ramp-down time
s
such that no overvoltage arises in the
inverter due to regenerative operation of the
motor, and such that the generated current
does not exceed the current limit set in
parameter 4-18 Current Limit. The value 0.00
corresponds to 0.01 s in speed mode. See
ramp-up time in parameter 3-61 Ramp 3
Ramp up Time.
Par . 3 − 62 =
t s x n RPM
acc s
ref RPM
Function:
. Select a ramp-up time such
s
t s x n RPM
dec s
ref RPM
43
4 4
