Parameter Lists
Par. No. # Parameter description
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-22 Terminal 54 Low Current
6-23 Terminal 54 High Current
6-24 Terminal 54 Low Ref./Feedb. Value
6-25 Terminal 54 High Ref./Feedb. Value
6-26 Terminal 54 Filter Time Constant
6-29 Terminal 54 mode
5 5
6-7* Analog/Digital Output 45
6-70 Terminal 45 Mode
6-71 Terminal 45 Analog Output
6-72 Terminal 45 Digital Output
6-73 Terminal 45 Output Min Scale
6-74 Terminal 45 Output Max Scale
6-76 Terminal 45 Output Bus Control
6-9* Analog/Digital Output 42
6-90 Terminal 42 Mode
6-91 Terminal 42 Analog Output
6-92 Terminal 42 Digital Output
6-93 Terminal 42 Output Min Scale
6-94 Terminal 42 Output Max Scale
6-96 Terminal 42 Output Bus Control
5.2.8 7-** Controllers
Par. No. # Parameter description
7-0* Speed PID Ctrl.
7-00 Speed PID Feedback Source
7-02 Speed PID Proportional Gain
7-03 Speed PID Integral Time
7-04 Speed PID Differentiation Time
7-05 Speed PID Diff. Gain Limit
7-06 Speed PID Lowpass Filter Time
7-07 Speed PID Feedback Gear Ratio
7-08 Speed PID Feed Forward Factor
7-1* Torque PID Ctrl.
7-12 Torque PID Proportional Gain
7-13 Torque PID Integration Time
7-2* Process Ctrl. Feedb
7-20 Process CL Feedback 1 Resource
7-22 Process CL Feedback 2 Resource
7-3* Process PID Ctrl.
7-30 Process PID Normal/ Inverse Control
7-31 Process PID Anti Windup
7-32 Process PID Start Speed
7-33 Process PID Proportional Gain
7-34 Process PID Integral Time
7-35 Process PID Differentiation Time
130
®
VLT AutomationDrive FC 360
Default value
0.07 V
10 V
4 mA
20 mA
0 N/A
ExpressionLimit
0.01 s
[1] Voltage mode
[0] 0-20 mA
[0] No operation
[0] No operation
0%
100%
0 N/A
[0] 0-20 mA
[0] No operation
[0] No operation
0%
100%
0 N/A
Default value
[20] None
0.015 N/A
8 ms
30 ms
5 N/A
10 ms
1 N/A
0%
100%
0.020 s
[0] No function
[0] No function
[0] Normal
[1] On
0 RPM
0.01 N/A
9999 s
0 s
Danfoss A/S © 7/2015 All rights reserved.
2-set-up Change Conversion
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2-set-up Change Conversion
during
operation
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
index
-2 Uint16
-2 Uint16
-5 Uint16
-5 Uint16
-3 Int32
-3 Int32
-2 Uint16
– Uint8
– Uint8
– Uint8
– Uint8
-2 Uint16
-2 Uint16
0 Uint16
– Uint8
– Uint8
– Uint8
-2 Uint16
-2 Uint16
0 Uint16
Type
index
– Uint8
-3 Uint16
-4 Uint32
-4 Uint16
-1 Uint16
-4 Uint16
-4 Uint32
0 Uint16
0 Uint16
-3 Uint16
– Uint8
– Uint8
– Uint8
– Uint8
67 Uint16
-2 Uint16
-2 Uint32
-2 Uint16
