Parameter Descriptions
9-16 PCD Read Configuration
Select the parameters to be assigned to PCD 3–10 of the
telegrams. The number of available PCDs depends on the
telegram type. Values in PCD 3 to 10 contain the actual data
values of the selected parameters.
Option:
[1663] Terminal 54 Setting
[1664] Analog Input AI54
[1665] Analog Output 42 [mA]
[1667] Pulse Input 29[Hz]
[1668] Pulse Input 33 [Hz]
[1669] Pulse Output 27 [Hz]
[1670] Pulse Output 29 [Hz]
[1671] Relay Output
[1672] Counter A
[1673] Counter B
[1679] Analog Output AO45
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1697] Alarm Word 3
[3421] PCD 1 Read For Application
[3422] PCD 2 Read For Application
[3423] PCD 3 Read For Application
[3424] PCD 4 Read For Application
[3425] PCD 5 Read For Application
[3426] PCD 6 Read For Application
[3427] PCD 7 Read For Application
[3428] PCD 8 Read For Application
[3429] PCD 9 Read For Application
[3430] PCD 10 Read For Application
[3450] Actual Position
[3456] Track Error
9-18 Node Address
Range: Function:
126 [ 0 - Enter the station address in this parameter or,
*
126 ] alternatively, in the hardware switch. To adjust the
station address in parameter 9-18 Node Address,
set the hardware switch to 126 or 127 (that is all
switches set to on). Otherwise, this parameter
shows the actual setting of the switch.
9-19 Drive Unit System Number
Range: Function:
1037 [0 - 65535 ] Manufacturer specific system ID.
*
MG06C602
Programming Guide
9-22 Telegram Selection
Option:
[1]
Function:
[100]
*
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[200]
9-23 Parameters for Signals
Option:
[0]
*
[302]
[303]
[312]
[341]
[342]
[351]
[352]
[380]
[381]
[412]
[414]
[416]
[417]
[553]
[558]
[590]
[593]
[595]
[615]
[625]
[696]
[748]
[890]
[891]
[1500]
[1501]
[1502]
[1600]
[1601]
[1602]
Danfoss A/S © 7/2015 All rights reserved.
Function:
Standard telegram Select a standard PROFIBUS
1 telegram configuration for the
frequency converter as an
alternative to using the freely
configurable telegrams in
parameter 9-15 PCD Write Configu-
ration and parameter 9-16 PCD Read
Configuration.
None
PPO 1
PPO 2
PPO 3
PPO 4
PPO 5
PPO 6
PPO 7
PPO 8
Custom telegram 1
Minimum Reference
Maximum Reference
Catch up/slow Down Value
Ramp 1 Ramp Up Time
Ramp 1 Ramp Down Time
Ramp 2 Ramp Up Time
Ramp 2 Ramp Down Time
Jog Ramp Time
Quick Stop Ramp Time
Motor Speed Low Limit [Hz]
Motor Speed High Limit [Hz]
Torque Limit Motor Mode
Torque Limit Generator Mode
Term. 29 High Ref./Feedb. Value
Term. 33 High Ref./Feedb. Value
Digital & Relay Bus Control
Pulse Out 27 Bus Control
Pulse Out 29 Bus Control
Terminal 53 High Ref./Feedb. Value
Terminal 54 High Ref./Feedb. Value
Terminal 42 Output Bus Control
PCD Feed Forward
Bus Jog 1 Speed
Bus Jog 2 Speed
Operating hours
Running Hours
kWh Counter
Control Word
Reference [Unit]
Reference [%]
4 4
Function:
79
