Parameter Descriptions
8-32 Baud Rate
Option:
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
4 4
[7] 115200 Baud
8-33 Parity / Stop Bits
Option:
[0] Even Parity, 1 Stop Bit
*
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-35 Minimum Response Delay
Range:
0.01 s [ 0.0010 - 0.5
*
s]
8-36 Maximum Response Delay
Range:
Size related
*
s]
8-37 Maximum Inter-char delay
Range:
0.025 s [0.025 - 0.025
*
s]
4.9.4 8-4* FC MC Protocol Set
8-42 PCD Write Configuration
Enter up to 16 different preset mapping (0-15) in this parameter,
using array programming. If this parameter is active, addresses
from 2810 to 2825 represent values of the 16 parameters. If this
parameter is not active, addresses 2810 and 2811 are used as
input-data-drive control word and bus reference. Addresses from
2812 to 2825 are reserved.
Option:
[0]
[1]
[2]
[3]
74
Function:
Function:
Specify the minimum delay time
between receiving a request and
transmitting a response. This is used for
overcoming modem turn-around
delays.
Function:
[ 0.1 - 10.0 Specify the maximum permissible
delay time between receiving a
request and transmitting the response.
If this time is exceeded, no response
is returned.
Function:
Specify the maximum delay time
between 2 characters in a message.
Exceeding this delay time causes the
message to be discarded.
Function:
None
[302] Minimum Reference
[303] Maximum Reference
[341] Ramp 1 Ramp up time
Danfoss A/S © 7/2015 All rights reserved.
®
VLT AutomationDrive FC 360
8-42 PCD Write Configuration
Enter up to 16 different preset mapping (0-15) in this parameter,
using array programming. If this parameter is active, addresses
from 2810 to 2825 represent values of the 16 parameters. If this
parameter is not active, addresses 2810 and 2811 are used as
input-data-drive control word and bus reference. Addresses from
2812 to 2825 are reserved.
Option:
[4]
[5]
Function:
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
8-43 PCD Read Configuration
Enter up to 16 different preset mapping (0-15) in this parameter,
using array programming. If this parameter is active, addresses
from 2910 to 2925 represent values of the 16 parameters. If this
parameter is not active, addresses 2910 and 2911 are used as
status word register and main actual value. Addresses from 2912
to 2925 are reserved.
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
Function:
[342] Ramp 1 Ramp down
time
[351] Ramp 2 Ramp up time
[352] Ramp 2 Ramp down
time
[380] Jog Ramp Time
[381] Quick Stop Time
[412] Motor Speed Low Limit
[Hz]
[414] Motor Speed High Limit
[Hz]
[590] Digital & Relay Bus
Control
[676] Terminal45 Output Bus
Control
[696] Terminal 42 Output Bus
Control
[894] Bus Feedback 1
FC Port CTW
FC Port REF
None
[1500] Operation Hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1618] Motor Thermal
Function:
