Signal level: 80
Link quality: 95
•
Signal level: Indicates the reception level between end
unit and parent unit. If the level falls below 20% then the
logger should be placed in a better location or another
Repeater should be added.
•
Link quality: Calculation of the data transmitted with no
errors from the Repeater to the parent unit. If the level
falls between 85% then the Repeater should be placed in
a better location or another Repeater should be added.
The lower the link quality %, the more retries are needed
in order for the Repeater to send all of its data.
Note: The signal level may be low but the link quality can still
be 100%.
You will not be able to run the Signal Level test when the
Repeater has lost its connection to the network. If you tried,
then the following screens are displayed:
No Parent signal
Repeater Version
This menu informs the user of the Repeater firmware version.
This is helpful when you need to upgrade the system
firmware, to check the current version. Or when contacting
Fourier technical support, with any technical issues.
Rptr version:
2.03.00.01.89.00
Out of range
Fourier Systems
No Parent found
