DNL810
External Input
None
A.2.
Alarm Output (Output 1)
Open collector
Close position resistance: 50 Ω
Max. Load: 50 mA, 3 V DC
Overload protection
50 mA reset fuse
A.3.
Internal PT-100
Temperature
(DNL910)
Type: PT-100
Range: -20 to 50 ˚C
Resolution: 0.1 ˚C
Accuracy: ±0.3 ˚C
DNL910 and DNL920
Outputs
Logger Input
Specifications DNL910,
DNL920 and PA models
Internal Digital
Temperature
(DNL920)
Type: Digital sensor
Range: -20 to 50 ˚C
Resolution: 0.1 ˚C
Accuracy: ±0.5 ˚C
184
Internal Inputs
Digital Temperature
Digital Humidity
External Power Excitation
(transducers usage)
12 VDC @ 2 A
Internal Digital
Relative Humidity
(DNL920)
Range: 5 to 95 %
Resolution: 0.5%
Accuracy:
3% (DataNet software)
