system uses to communicate between Receiver and logger,
for all units in the system.
Figure 16: Showing network paths – Example 1
You can also select Show Path from the logger context menu
to display the individual path from the unit to the Receiver.
Using this option you can see exactly how the system is built.
Figure 17: Showing network paths – Example 2
The screenshot above shows a system of three loggers (red
squares) and two Repeaters (blue circles) transmitting to the
Receiver.
