Page 8: Introduction
21,000 samples per second, and of collecting up to 100,000 samples in its internal memory. TriLog is very easy to use because all of its functions are broken down into only four buttons. In addition, when a sensor is plugged in, the TriLog automatically recognizes the type of sensor it is, and will record the data with the appropriate units. -
Page 9: Chapter 1 Trilog
Chapter 1 TriLog This section will focus on the TriLog’s data collection device: The data logger. The section includes: • How to operate the TriLog’s keypad, • How to set up TriLog • How to connect TriLog to your PC. -
Page 10: External Connections
Normally, all four sockets can be used simultaneously. To connect a sensor to the TriLog use one of the sensor cables. Plug the stereo plug into the data logger, and the mini-din plug into the sensor - arrow facing down. -
Page 11: Battery
Battery TriLog is equipped with a 2.4V/850mAh NiMH rechargeable battery. Before you start working with TriLog for the first time, charge the unit for 10 to 12 hours while it is turned off. If the data logger’s main battery runs out, the internal 3V Lithium battery backs up the memory, so no data will be lost. -
Page 12: Stand-Alone Operation
1.2. Stand-Alone Operation One way to program the TriLog is to use the keypad and screen (The other way is to use MultiLab – see page 66, or ImagiProbe – see page 24). The keypad allows us to set all the parameters for data collection, while the LCD screen displays the setting values. -
Page 13: Sensors
Plug in the sensors Start with the first input on the right (see on page 10). If TriLog is in Auto ID mode (the default mode) it will identify the sensors you’ve plugged in and display the sensor’s name. -
Page 14: Working With The Trilog Keypad
The LCD screen will display: Logging At rates of up to 10 samples per second TriLog displays the recorded data values, the number of the last recorded data sample, and the total number of samples. Use the RATE button to scroll through the different sensor’s data and the number of samples. -
Page 15: The Display
The internal clock and calendar is kept updated even when the TriLog is turned off, but it will be erased if the 2.4V battery is dead. It will be updated the next time TriLog will be connected to a computer or a Palm. - Page 16 In the Continuous mode, TriLog does not save data, and can continue logging indefinitely. If TriLog is connected to the PC and the MultiLab software is running, the data is automatically transferred to the computer and displayed in a real time graph.
-
Page 17: Programming Rules And Limitations
Programming Rules and Limitations The following are some rules and limitations you must take into account when programming the TriLog, as TriLog integrates all programming limitations automatically. TriLog will only allow the programming of settings that comply with the rules below. 1.Sampling points: •... -
Page 18: Sensor Calibration
1.3. Sensor Calibration In this chapter you will learn how to increase the TriLog system accuracy using calibration. Most of the sensors are linear, i.e. the output level of each sensor changes according to the equation: Where: Y – The sensor’s output (voltage level varying from 0 to 5V) X –... -
Page 19: Ph Temperature Compensation
1.3.3. pH Temperature Compensation To compensate a pH sensor for temperature changes, plug the temperature sensor into Input 1, and the pH sensor in Input 2. TriLog will then display the compensated pH value. 1.3.4. MultiLab Sensor Calibration The sensors can also be calibrated using the Calibrate Sensors option in MultiLab’s Logger menu. -
Page 20: Chapter 2 Working With Palm Handheld And Imagiprobe
Chapter 2 Working with Palm Handheld and ImagiProbe 2.1. Install the Software 2.1.1. System Requirements To work with ImagiProbe, your Palm handheld device should be equipped with the following: • Approximately 300k of memory • Palm OS ® 3.5 or later 2.1.2. -
Page 21: Overview
2.2. Overview 2.2.1. ImagiProbe Layout The ImagiProbe application is designed to support four major kinds of activities: • Creating and viewing investigations • Creating and viewing data collection trials • Adding, viewing and editing sensors and their calibrations • Creating, viewing and editing notes The diagram below shows the ImagiProbe application's major modules and their interrelationships: Create Investigation... -
Page 22: Palm Panel Layout
Refer to the diagram below to interpret those references. Power Button Application Button Menu Icon Chapter 2 Working with Palm Handheld included with each sensor Alpha Keyboard Target Graffiti Write-in Areas Numeric Keyboard Target Scroll Buttons TriLog Connector Figure 6: Palm Panel Layout calibration... -
Page 23: Connecting Trilog To A Palm Handheld
TriLog. 3. Simultaneously depress release buttons on both sides of TriLog. 4. Lower the back of the Palm handheld onto the interface. 5. Release the buttons on the side of the interface to latch TriLog in place. Release Button... -
Page 24: Getting Started
After you have added and named a trial, you must specify the trial’s data collection parameters: the sensor(s) you have connected to TriLog and the sampling rate for the sensor(s). You may also choose to add notes to an investigation or trial. -
Page 25: Setting The Sampling Rate
When you complete your trial setup, you may wish to preview your data. In Preview you can: • Ensure that your handheld computer, TriLog and sensors are properly connected • Verify that a sensor is measuring what you intend it to measure •... -
Page 26: Changing The Scale For The Y-Axis
1. Tap Preview 2. Examine data as they change in the meter or as they are plotted in the Preview graph 3. You can toggle between sensors by tapping on the Input Selector 5.Changing the Scale for the Y-Axis By default, the ImagiProbe application sets the y-axis scale to correspond to the maximum and minimum values of a sensor’s range as specified in its calibration. -
Page 27: Selecting Working Mode
2. Tap the Options menu 3. Select Auto ID Sensors… 4. To enable TriLog’s Auto ID mode (see on page 12) tap the On button. To disable TriLog’s Auto ID mode tap on the Off button. The Auto ID function will remain in effect until the next time you change it 2.4.3. -
Page 28: Viewing Collected Data
2. Assign a sensor and its calibration to input 1 by tapping on the sensor picker and selecting a sensor name from the installed sensor list. The ImagiProbe 3.0 application will assign a default calibration for the sensor. If you wish to change the default calibration to another preinstalled calibration, tap the calibration picker 3. -
Page 29: Zooming In And Out Of Data
Note: To view values for a different sensor you must toggle between the sensors by tapping the Input Selector icon. 3.Zooming In and Out of Data To zoom in or out of data: 1. Move to the graph page that contains the values you wish to view more closely 2. -
Page 30: Editing Text Notes
4. When you have finished adding text notes, tap Done to return to the previous form. Your notes are automatically saved 2.Editing Text Notes Editing a text note with Graffiti To edit text in a note, from a Notes form: 1. -
Page 31: Viewing An Existing Trial
Erasing Text Notes To erase a text note, from the Notes form: 1. Tap the text to highlight the material you wish to erase. 2. Use the Graffiti backstroke to delete the text. 2.4.6. Viewing an Existing Trial To view an existing trial, from the Investigations form: 1. -
Page 32: Deleting Trials
4. Select Delete Investigation. 5. Tap OK when prompted 2.Deleting Trials To delete a trial and its notes, from the Trial form: 1. Tap the Menu icon on your handheld computer to display the ImagiProbe application menus 2. Select the Action menu 3. -
Page 33: Working With Sensors And Calibrations
2.5. Working with Sensors and Calibrations The ImagiProbe installer includes calibrations for commonly used sensors (e.g. Light, Temperature, Voltage, and pH).You can view the list of installed sensors and calibrations from the Sensor module. Use the Sensor module to create new sensors and calibrations. -
Page 34: Viewing And Editing Calibrations And Their Notes
2.5.3. Viewing and Editing Calibrations and Their Notes To view calibrations, from the Sensor form: 1. Scroll through the list of calibrations 2. Tap on a calibration (e.g. 0 to 600 lux) in the calibration list 3. Tap the Notes icon to view and edit notes for that calibration 4. - Page 35 3. Specify units for the sensor (e.g. g) 4. Select Equation from the Calibrate by picker. 5. Referring to the documentation provided with the sensor, enter values for the slope and the y-intercept of the calibration curve. 6. Tap Save Calibrating a Linear Sensor by Reference To calibrate a sensor by reference, from the View Sensor form: 1.
-
Page 36: Adding Non-Linear Sensors
8. Repeat steps 4 to 7 to add a second reference value pair 9. Tap Save 3.Adding Non-Linear Sensors To add a non-linear sensor, from the Sensor List: 1. Tap New Sensor 2. Select one of the non-linear types from the Choose Sensor Type dialog and tap OK 4.Adding Non-Linear Calibrations The ImagiProbe application enables you to calibrate non-linear sensors by equation... -
Page 37: Deleting Calibrations
2.5.6. Deleting Calibrations To delete a calibration, from the Sensor list: 1. Tap on a sensor name for which you wish to delete a calibration 2. Tap on the calibration you wish to delete 3. Tap the Menu icon, or press the Menu key on your handheld computer to display the ImagiProbe application menus 4. -
Page 38: Deleting Sensor Databases Before Merging
3. Double-click on that file name to open the Install Handheld Files Window of the HotSync Manager or open the Palm HotSync Manager and select Install Handheld files from the HotSync menu 4. Drag all the sensor databases you wish to install into the Install Handheld Files window 5. -
Page 39: Adding Content To Imagiprobe 3.0
2.6. Adding Content to ImagiProbe 3.0 You can create and save content databases of your favorite activities and install these in advance on other Palm Powered computers. Content databases can include investigations complete with notes and trial setups. Follow a three-step process to add content to the ImagiProbe 3.0 application. -
Page 40: Installing Content Databases Using Hotsync
6. Follow the on-screen instructions to complete the beaming procedure 2.Installing Content Databases Using HotSync The HotSync method requires two steps: a) placing the database on the desktop computer; b) using HotSync to copy the database from the computer to other Palm Powered devices. -
Page 41: Deleting Content Databases Before Merging
Note: The merging process adds the content to any investigations and trials you may have already saved in the ImagiProbe application. The merging process will resolve naming conflicts automatically by renaming investigations and trials. 2.6.4. Deleting Content Databases before Merging You cannot select a particular database from among multiple installable databases for merging. -
Page 42: Hotsync For Macintosh
1. Place your handheld computer in the cradle 2. Press the HotSync button on the cradle 2.HotSync for Macintosh ® System requirements for the ImagiProbe conduit are those of Palm Desktop 4: Mac OS X (version10.1.2 or higher) or Mac OS 9.x See http://www.palm.com/software/desktop/mac.html. -
Page 43: Working With Imagiprobe Data On A Desktop Computer
report samples in elapsed time instead of time of day. You may wish to change these default settings. To copy data from the handheld computer to another folder on a Windows computer, click on the HotSync Manager icon located on the task bar: 1. -
Page 44: Navigating Investigations In A Browser On A Desktop Computer
When you copy files to a desktop computer with HotSync, the ImagiProbe conduit creates a folder hierarchy ordered from the top by user/investigation/trial. The ImagiProbe conduit names the top-level folder “<username> Investigations” (e.g. Rhonda Investigations) where <username> represents the user name installed on the handheld computer. - Page 45 4. Click on a Trial link to open a specific trial. The HTML page for a trial will display the trial setup for the trial. Also, if you added notes to a trial, you will see them on the page pertaining to that trial Figure 9: ImagiProbe Trial Page 5.
-
Page 46: Importing Trial Data Into Multilab
Note: The HTML table may not be available for larger trials. In this case, you must view the data as text in the browser. 2.Importing Trial Data into MultiLab When you copy files to a desktop computer with HotSync, the ImagiProbe conduit creates text files containing the trial’s data. -
Page 47: Chapter 3 Working With Multilab
(and you have already installed MultiLab), click Cancel to stop installation 2. Connect the TriLog to a USB port on your PC and turn the TriLog on. Windows will automatically detect the new device and open the Add New Hardware Wizard... - Page 48 3. Select Specify the location of the driver, then click Next 4. Select Search for the best driver for your device, then check the Removable Media checkbox, and then click Next Windows will automatically detect and install the necessary software. Chapter 3 Working with MultiLab...
-
Page 49: Overview
The most commonly used tools and commands are displayed on three toolbars. Tools that relate to all aspects of the program and tools that control the TriLog are located in the main (upper) toolbar. Tools specific to the graphs are located on the graph toolbar and tools specific to the tables are located on the table toolbar. -
Page 50: Working With Projects
All the information you collect and process for a given experiment is stored in a single project file. Each of these files contain all the data sets you collect with the TriLog, the analysis functions you’ve processed, the video files you’ve recorded, specific graphs and tables you’ve created, and the MultiLab settings for the experiment. -
Page 51: Getting Started
3.3. Getting Started 3.3.1. Set up a Recording Session Prepare TriLog 1. Connect TriLog to the PC (see page 10) 2. Turn on TriLog 3. Plug in any external sensors 4. Open the MultiLab software Enable Video Recording 1. Connect the camera to the PC 2. -
Page 52: Single Measurement
1. Single measurement MultiLab will open a new project file every time you start a new recording session. 2. Replace MultiLab will display the new data set in place of the old one. The project’s old data sets will still be available in the same project file. They will be listed in the Data Map and you can add them to the display at any time 3. -
Page 53: Video And Audio Properties
Experiment. Online communication When TriLog is connected to the PC and programmed to run at sampling rates of up to 100/s, TriLog transmits each data sample immediately, as it is recorded, to the PC. The software thus displays the data in real-time in both the graph window and the table window. -
Page 54: Save Data
PC and displayed. Off-line data logging To download data that was recorded offline, or while TriLog was not connected to a PC, connect TriLog to the computer, run the MultiLab program and click Download on the toolbar. This will initiate the Post-Experiment Data Transfer communication mode. -
Page 55: Create A New Project
3.3.7. Create a New Project There are three ways to create a new project: 1. Open the MultiLab program, which will open a new file each time 2. When working in Single Measurement mode, a new project is opened every time you click on the Run button to start a new recording 3. -
Page 56: Print
5. In the Save as type list, click the CSV format 6. Click Save To import files that were previously exported from MultiLab open MultiLab and import the file as described above as they are already in CSV format. 3.3.9. Print 1.Print a graph 1. -
Page 57: View The Data
3.4. View the Data 3.4.1. Display Options The MultiLab program’s screen consists of four parts: the graph window, table window, video window and Data Map window. You can display all four parts simultaneously (the default view) or any combination of the four. The graph window is the main window by default and is and displayed in the center of the application window. -
Page 58: Split Graph View
1. Split graph view MultiLab enables you to display your data in two separate graphs within the graph window. 1. Click Split graph into two separate graphs 2. Click Edit graph dialog box 3. Choose which data sets to display on each of the graphs (or use the Data Map to do so –... -
Page 59: Zooming
3. Zooming 1. To zoom in to the center of the graph 1. Click Zoom in 2. To reverse the operation, click Zoom out 2. To zoom in to a specific data point 1. Select the point with the cursor (see above) 2. -
Page 60: Panning
To restore auto scaling click Autoscale 7. The stretch/compress axis tool Move the cursor onto one of the graph axes. The cursor icon changes to the double ↔ arrow symbol ( ), indicating that you can stretch or compress the axis scale. Drag the cursor to the desired location. -
Page 61: Format The Graph
5. To select a data set for display on the X-axis, click on the data set’s name in the X-axis list. You can only select one data set at a time for the X-axis 6. Type in the title of the graph in the Graph title edit box (optional) 7. -
Page 62: The Table Display
3.4.3. The Table Display Click Table to display or to remove the table window. When you start a new recording, MultiLab displays the new data on the table. To add or remove columns from the table, use the Edit table tool (see below). 1. -
Page 63: Formatting The Table
3. Formatting the table 1. Changing column width Drag the boundary on the right side of the column heading until the column is the desired width. 2. Changing row height Drag the boundary below the row heading until the row is the desired height. 3. -
Page 64: Data Map
2. Select the meter type, and the data set to be displayed 3. A list entry that begins with a graph number denotes a displayed data set. A list entry that begins with an input number denotes the next recording, and will be displayed on the meter the next time you start a recording 4. -
Page 65: Export Data To Excel
Individual function – currently displayed on graph 1 Individual function – currently displayed on graph 2 Individual function – currently displayed both on graphs 1 and 2 Function Experiment – includes all recorded data of the experiment Individual data set – currently not on display Individual data set –... -
Page 66: Program Trilog
The first step is to assign sensors to each input. If you are working with TriLog in Auto ID mode, the sensors are selected automatically as you plug them in to the TriLog. Otherwise, you can manually select the sensors you are using from the corresponding input drop lists. -
Page 67: Define Sensor Properties
Triggering to open the triggering dialog box (see page 69) 9. Click Finish to complete the setup and to send the setup command to the TriLog 2. Define sensor properties Some of the sensors can produce more than one measurement. For example, the distance sensor measures distance, but MultiLab also calculates the velocity and acceleration of the measured body in real time. -
Page 68: Presetting The Display
You can define the properties of each sensor individually in the first step of the Setup wizard, or by selecting Sensor properties from the Logger menu. 1. Click Setup wizard wizard 2. Click Properties 3. Click the check boxes next to the desired measurements 4. -
Page 69: Power Saving Mode
5. Click OK 5.Power saving mode To enable TriLog’s power saving mode (see on page 11) check the Power saving mode check box in step 2 of the Setup wizard. Note: the Power saving mode check box is enabled only after selecting recording rate that is equal to or less then 1 sample every minute. - Page 70 3. Select the trigger level in the Level drop list 4. Click OK Note: When you turn off TriLog, it will save the setup for the next session. Chapter 3 Working with MultiLab...
-
Page 71: Start Recording
Click Stop on the main toolbar 3.5.4. Clear TriLog’s Memory To erase all experiment data currently stored in the TriLog, click Clear memory in the Logger menu (TriLog must first be connected to the PC). 3.5.5. Select TriLog’s operating mode To enable TriLog’s Auto ID mode (see on page 12):... -
Page 72: Define A Custom Sensor
To determine whether your sensor has a code resistor or not, simply plug it in to TriLog (while in Auto ID mode) and see if TriLog displays the setup menu and the sensor name. -
Page 73: Communication Setup
Note: In case of any communication malfunction, please refer to Chapter 4: trouble shooting guide. 3. You can click Work offline if you wish to work without TriLog. While working offline, you can still open saved files to view and analyze... -
Page 74: Analyze The Data
3.6. Analyze the data 3.6.1. Reading Data Point Coordinates Position the cursor (see page 58) on a point to display its coordinates on the information bar at the bottom of the graph window. If more than one curve is displayed, and you want to read the Y- coordinates of all of the curves simultaneously, bring up digital meters (see page 63) for each of the curves. -
Page 75: Statistics
3.6.5. Statistics Use the statistics tool to display statistics of a selected data set or a range of data. The statistics include: Average – The average of all the numbers in the range. StDev. – The standard deviation Minimum – The smallest value in the range. Maximum –... -
Page 76: The Analysis Wizard
3.6.7. The Analysis Wizard 1.Using the Analysis Wizard The analysis wizard will guide you through the various analysis functions available in the MultiLab program. The analysis functions are grouped into three main categories: curve fit (regression), averaging, and mathematical and trigonometric functions. To apply an analysis function to a data set: 1. -
Page 77: Averaging
5. Click the Show R on graph check box to display the correlation coefficient on the information bar 6. Click OK Note: If you want the automatic curve fit equation to start at the crop tool before any type of curve fitting (see page 89). 3.Averaging Figure 24: Analysis wizard –... -
Page 78: Functions
4.Functions Figure 25: Analysis wizard – functions 1. Select a function from the Functions list. MultiLab displays the function’s formula at the bottom of the dialog box 2. If you use the cursor to select a data set, it will be highlighted in the G1 drop list, but you have the option of selecting a different data set 3. -
Page 79: Averaging
Polynomial Draws a line of polynomial least square fit (you must select an order between 1 and 6.) Power Draws a line of power least square fit. Exponential Draws a line of exponential least square fit. MultiLab displays the curve fit equation and the correlation coefficient (R information bar below the graph 2.Averaging The average function replaces every point with the average of n neighboring points... - Page 80 Replaces every point with the averaging of C Cosine cos( Draws a line of the cosine values of a data set. The argument must be expressed in radians. − Delta Y Draws a line of the difference between the Y-coordinate of every point and Y-coordinate of the first point.
- Page 81 Draws a line of Fourier Discrete Fourier transform of G transform Draws a line of the amplitudes of the harmonics of Fourier transform vs. frequency. The frequency of G1 (minimum of C Frequency Draws a line of the frequency of a periodic data set vs. time. The constant C defines the minimum data points in one cycle.
-
Page 82: Online Analysis
Reciprocal (1/X) Draws a line of the reciprocal values of a data set. Sine sin( Draws a line of the sine values of a data set. The argument must be expressed in radians. Square (X Draws a line of the squares of a data set. Square root Draws a line of the square root values of a data set. - Page 83 Figure 26: Analysis wizard – online functions 2. Select Envelope (upper) from the Functions list 3. Select Input 1: Angle from the G1 drop list 4. Click OK 5. Click Edit graph on the graph toolbar to open the Graph edit dialog box: Figure 27: Using graph edit dialog to display online functions 6.
-
Page 84: Manual Curve Fitting
9. Click Run display the original data readings coming from Input 1, as well as the data processed by the analysis function: Figure 28: Online envelope function The online analysis function will still be active in subsequent recordings. To remove the online functions, click Analysis on the menu bar and then click Clear online functions. - Page 85 Power Draws a line of the time raised to the power of a number from –5 to 5. Note: If you want the curve fit equation to start at tool before any type of curve fitting (see page 89). To apply manual curve fit: 1.
-
Page 86: Workbook
The Workbook is an online library of experiment manuals called “worksheets,” that appear in Web-page format. Each worksheet includes an experiment template that automatically configures both the MultiLab and TriLog at the push of a button. To begin recording, all you need to do is click Run. -
Page 87: Create Your Own Worksheet
(see below). The second step is to use the MultiLab software to create a configuration file, which is a file that will store the specific settings you wish to define for the experiment. These include the TriLog setup, MultiLab’s layout, the recording mode, the graph format desired, special preset graph scaling, sensors measurement etc. - Page 88 3. Double click the file you want to configure to open it: 4. Click Enter experiment settings to open the Setup wizard 5. Use the setup wizard to preset MultiLab and TriLog just as with the normal setup process (see page 66) 6.
-
Page 89: Special Tools
1. Click Run 2. Click Pause/Continue Data transmitted from the TriLog while the graph is frozen is stored onto the PC but is not displayed. 3. Click on the end of the curve and move the mouse according to your predictions. -
Page 90: Measuring Methods
2. Click Analysis on the menu bar, then click Timing Wizard to open step 1 of the Timing Wizard dialog: Figure 32: Timing Wizard – Measurement 3. Click an option to select measurement: Time, Velocity or Acceleration 4. Click Next to move to step 2: Figure 33: Timing Wizard –... - Page 91 The methods depend on the selected measurement: Time • At one gate • Between gates • Pendulum Velocity • At one gate Measures the time it takes the body to cross the photogate (between blocking unblocking the infrared beam) Measures the time it takes the body move from...
- Page 92 • Between gates • Collisions Acceleration • At one gate • Between gates Chapter 3 Working with MultiLab Measures the time it takes the body move from photogate second photogate (between blocking first blocking second infrared beams) and returns the average velocity. You should enter the distance between gates Measures the crossing time...
-
Page 93: Time Schemes And Calculations
4.Time schemes and calculations Time measurements At one gate ∆ Result: Between gates Input 1 Input 2 ∆ Result: Pendulum (one gate) ∆ Result: − − − Chapter 3 Working with MultiLab... - Page 94 Velocity At one gate Required parameters: w – the body’s width Result: ∆ Between gates Required parameters: L – the distance between gates Input 1 Input 2 Result: ∆ Collision (two gates) Required parameters: w – the bodies’ width (must be identical) Input 1 Chapter 3 Working with MultiLab ∆...
- Page 95 Input 2 Result: Acceleration gate Required parameters: w – the flags’ width Input 1 ∆ Result: − − − − ∆t − − − − − ∆ Chapter 3 Working with MultiLab...
-
Page 96: Tips On Using The Timing Wizard
Between gates Required parameters: w – the body’s width Input 1 Input 2 ∆ Result: 5.Tips on using the Timing Wizard • Attach a flag to the moving body When measuring the motion of a moving cart it is convenient to attach a vertical ‘flag’ to the cart (see picture below). -
Page 97: Crop Tool
The Capture tool enables you to capture and record specific data points from the TriLog stream of data, like taking snapshots of the dynamic process. For example, you can design a light refraction experiment that will record the angle of the refracted... -
Page 98: Preparing The Capture Table
beam only when the light intensity is maximal, and then plot the angle of refraction vs. the manually entered column of the angle of the incident beam. In capture mode, when you start recording, the data in the graph window appears as it normally does, but every time you click Capture, MultiLab enters the most recently recorded value into a new entry in the capture table. -
Page 99: Capturing Data
Figure 36: Capture table 2. Capturing data 1. Click Run on the main toolbar to start the data recording process 2. Watch the online graph, and when the graph reaches a point you wish to capture, click Capture enters the momentary data to the capture table sequentially 3. - Page 100 2. Choose the data set that you wish to display on the X–axis from the X–Axis list by clicking its name 3. Choose the data set or sets you wish to display on the Y–axis from the Y–Axis list by clicking its name (or names) 4.
-
Page 101: Toolbar Buttons
3.9. Toolbar Buttons 3.9.1. Main (upper) Toolbar Start new project Open saved project Open Save project Save Select print options Print Start a data recording session. Click on the down-arrow to select recording mode Stop recording Stop Download the data from the most recent recording Download session Open the Setup dialog box... -
Page 102: Graph Toolbar
Replay video and/or data Play Pause replaying Pause Record video Record 3.9.2. Graph Toolbar Zoom in Zoom out Autoscale Zoom to selection More smoothing Less smoothing Cursor Cursor Split graph Edit graph Graph properties Add to project Export to Excel Pause/Continue 102 Chapter 3 Working with MultiLab Zoom in around a selected point or in to a selected... -
Page 103: Table Toolbar
Add a prediction onto the graph Add prediction Erase the selected prediction Erase prediction 3.9.3. Table Toolbar Add/remove columns from the table Edit table Format fonts and units Table properties Add the current table to the project Add to project Save the present data Capture Chapter 3 Working with MultiLab 103... -
Page 104: Chapter 4 Troubleshooting Guide
Chapter 4 Troubleshooting Guide 4.1.1. General Symptom I pressed the ON key on TriLog and it did not turn on. I see voltage units when sampling using the microphone. I started a new logging and the data logger stopped immediately afterwards. -
Page 105: Troubleshooting The Imagiprobe Application
Cause of problem • Charge TriLog completely (12 hours) • Use TriLog while connected to a wall outlet • If the sensor is not completely inserted, the Auto ID function cannot properly identify the sensor. Disconnect the sensor and firmly reconnect. -
Page 106: Troubleshooting The Imagiprobe Conduit
Symptom Palm Powered computer won’t save data ImagiProbe was unable to connect to TriLog or to recognize plugged-in sensors 4.1.3. Troubleshooting the ImagiProbe Conduit Symptom Nothing happens when I use HotSync to transfer data to the desktop A blank graphic icon appears in... -
Page 107: Troubleshooting Multilab
• There is no available COM Port. • There may be up to 100 experiments stored in the TriLog. Performing a “Download” means loading one of them in sequential order. You have probably loaded an old experiment accidentally. Try using Selective download from MultiLab (see page 53) •... - Page 108 Symptom I can’t record voice comments 108 Chapter 4 Troubleshooting Cause of problem • The microphone volume is muted. Open Window’s volume control and uncheck the Mute check box at the bottom of the Mic volume column.
-
Page 109: Chapter 5 Specifications
Digital sampling rate: >200 kHz Resolution 12 bit (4096 Levels) Man-machine interface Full keypad operation enabling manual programming of TriLog Alfa Numeric LCD, 2 lines by 16 characters each Features Stand alone operation working and sampling without connection to a PC... -
Page 110: Sensors
DT 224 - Sensor Cable Connects TriLog to sensors DT 023 -VERNIER Sensor Adaptor Enables the connection of all VERNIER analog sensors (with DIN plugs) to TriLog. For further information please contact your local TriLog dealer. 110 Chapter 5 Specifications... -
Page 111: Imagiprobe Software (Palm™ Handheld)
DT 231 –Serial Communication Cable Connects TriLog to a serial port on the PC DT207 –Mini USB Communication Cable Connects TriLog to a USB port on the PC AD23605 –AC/DC adaptor Connects TriLog to EUR mains power 35AD06500 –AC/DC adaptor Connects TriLog to USA mains power 4.ImagiProbe Software (Palm™... - Page 112 Windows 95 or later (Windows 95 and Windows NT will not support video recording) Internet Explorer 5.0 or later (Internet Explorer 5 is included in the TriLog) Hardware Pentium II 300MHz or higher (Pentium 200MHz or higher for use without...
-
Page 113: Appendix A: Figures
Appendix A: Figures Figure 1: Contents of the TriLog system ...9 Figure 2: TriLog external connections ...10 Figure 3: TriLog front panel ...12 Figure 4: Frequency Aliasing...16 Figure 5: schematic diagram of ImagiProbe modules...21 Figure 6: Palm Panel Layout ...22 Figure 7: Connecting Palm Handheld to TriLog ...23... -
Page 114: Appendix B: Adding A Code Resistor To A Custom Sensor
Appendix B: Adding a code resistor to a custom sensor In order for TriLog to automatically identify a sensor, it must have a code resistor. Figure 38 shows the TriLog sensor plug configuration. You must connect the resistor between the ID resistor input and the GND input. - Page 115 · 52 open · 54 Palm handheld · 20 panel · 12 panning · 60 pH sensor · 19 port · 11, 73 predict · 89 preset · 68 preview · 25 program rules · 17 TriLog · 66 Index 115...
- Page 116 project · 50, 55 properties graph · 61 sensor · 67 table · 63 video · 53 rate · 15, 17, 25, 67, 104, recording data · 14, 51 options · 51 rate · See rate start · 14, 26, 71 stop ·...
