Turn off unit
Note: Turning off the logger when in Short Range Repeater
mode can have adverse affects on your network, as other
units may be dependent on the Repeater for transmitting its
data to the Receiver. To prevent the SRR from being a point
of failure if shut off, ensure the network is robust enough by
having alternative routes for the end units to reach the
Receiver.
Min/Max Values Menu
Each sensor's minimum/maximum readings (taken from the
current logging session) will be displayed on two rows.
The first row indicates the sensor type, along with the
measurement units e.g. V, and the alarm indication if there is
an active alarm on this sensor.
The second row indicates the minimum and maximum
measured value and the units. H and L represent High and
Low values, respectively.
In-TMP ˚C
26.06H 25.61L
3.12.5.

Additional Logger Screens

Unit Beep
When the DataNet software activates the Call Unit feature, the
logger will beep and the following screen will be displayed:
