3.11.2. DNL804, DNL808,
DNL810 and
DNR800 Keypad
The Mini DataNet units have one button
on the keypad. This button is multi-
functional and is used to perform
various functions such as:
•
Turning on/off the unit
•
Starting signal test
The Menu button
functionalities:
Navigate to the main menu. When
pressed from within a submenu, the
display will take you back to the main
menu.
Selecting an option from one of the
menus. When pressed on one of the
main menu items, it will take you to
the sub menu options.
The Scroll button
functionalities:
When the unit is off, pressing this
button will power the unit on.
Scrolls through the menu options.
