Figure 6: Adding Receiver icon to Map View

A green icon indicates that the Receiver is online.
Note: If the Receiver is not recognized by the software try
connecting the mini-USB cable to another USB port on the
PC. Or select Network > Detect Receiver in the main menu.
Should you disconnect the Receiver's USB cable or
power adapter (and the battery eventually dies), the
Receiver icon will be grayed out:
5. Go to Network > Form New Network. The Receiver will
then form a new network based on your RF environment
rather than use the network formed in the factory. This will
ensure optimal network performance. Refer to section 2.8:
Optimizing the Network for more details.
Check the DataNet network ID that was formed by the
Receiver by placing the mouse cursor over the Receiver
icon. The network ID as well as Receiver firmware version
and unit serial number is displayed.

Figure 7: Receiver tooltip

Note: You can move the Receiver icon elsewhere on the
screen by going to Tools > Lock Map View and unselecting
this option.
18
