3.2.4.

DNL810

The DNL810 doesn't have any external connections. It has
two internal sensors only, temperature and humidity.
3.3. DNR800 Mini Repeater
Front Panel Layout

Figure 23: DNR800 Mini Repeater front panel

Multi-function button: Use to execute logger commands.
Dual–color LED indicator: Indicates status of Repeater such
as joining network, leaving network, etc.
Multi-function Multi-function
button button
Dual-color Dual-color
LED indicator LED indicator
44
