Logger newly acquired by network and
•
awaiting Setup.
Running from external power supply.
Logger which has received its Setup but is in
•
Stop mode.
Running from internal battery supply.
Logger which has received its Setup but is in
•
Stop mode.
Running from external power supply.
Logger in Run mode and running on battery
•
supply.
Green indicates there are no alarms.
Logger in Run mode and running on external
•
power supply.
Green indicates there are no alarms.
Logger in Run mode with an alarm alert.
•
Running from internal battery supply.
Logger in Run mode with an alarm alert.
•
Running from external power supply.
Logger is offline and is no longer detected on
•
the network. Its power supply may have failed
or it's out of range of the Receiver.
Logger is processing a command sent from the
•
software.
Logger is downloading data.
•
