Fourier DataNet User Manual page 82

Logger Version
This menu informs the user of the logger firmware version.
This is helpful when you need to upgrade the system
firmware, to check the current version. Or when contacting
Fourier technical support, with any technical issues.
Logger version:
2.03.00.01.89.00
The firmware version is commonly referred to by the numbers
in bold in the screen above. For example, the firmware
version which is supported by this user guide is v1.89.
S/N
This menu displays the unit's eight digit SN.
S/N 12345678
Network Data
This menu displays the unique network ID to which the unit is
currently connected. This ID will match the network ID
displayed in the software in the Receiver icon's tooltip in the
Map View.
Network data:
ID: 014.061.082
Device Mode
There are two possible device modes:
•
DataNet Logger
Device is operating as standard data logger
72
