3.4. DNR900
Receiver/Repeater Front
Panel Layout

Figure 24: Receiver/Repeater front panel

LCD screen
Displays Receiver/Repeater status and network information.
Menu/Enter button
Use to enter logger menu options and to execute logger commands.
Scroll button
Use to scroll though menu items and to power on unit.
LCD screen
Menu/Enter button
Scroll button
