The most commonly used tools and commands are displayed
on two toolbars. Tools that relate to all aspects of the program
are located in the main (upper) toolbar. Tools specific to the
graphs are located on the graph (lower) toolbar.
Refer to section 4.2.5 for a description of these toolbars
4.2.1.

Map View

When DataNet is first launched, the default window that is
opened is the Map View (see screenshot below).
You can also switch to Map View at any time by clicking the
Map View button in the main toolbar.
This view is used to monitor the location and network
connection of all of the data loggers and Repeaters in the
network, in addition to the Receiver.
Icons are used to represent each of the DataNet units, and
using the mouse the user can select specific actions to be
performed on the unit.

Figure 34: Main window - Map View

99
