Table 4: Main Toolbar Icon List - Fourier DataNet User Manual

Repeater is online and is running from external
•
power supply.
Repeater is offline and is no longer detected on
•
the network. Its power supply may have failed
or it's out of range of the Receiver.

Table 4: Main toolbar icon list

Graph (Lower) Toolbar Icons
The graph toolbar is located at the bottom of the open graph
view, when the user is either in Online Data Display:
Or History View:
The toolbar cannot be moved or hidden.
Data Map (in History View only) – Hides or
•
shows the Data Map pane in the History View
window.
Plot Legend (in Display Data View only) –
•
Hides or shows the sensor labels from the
bottom of the graph.
Autoscale - Returns the data to its default
•
scale.
Zoom in – Zooms in on the graph data.
•
Pan graph – Pans the graph along the x or y
•
axis.
108
