Displayed external sensor data set
•
Hidden internal sensor data set
•
Displayed graph function
•
Hidden graph function
•
Parent node for all logger data sets. Click to
•
expand or collapse all child nodes.
Logger data set. Click to expand or collapse
•
the data set containing all measured inputs of
the specific logger.
Parent node for all custom graph views. Click
•
to expand or collapse all child nodes.
Displayed custom graph view. When hidden
•
the icon is grayed out.

Table 6: Data Map icons

4.3.

File Menu Items

4.3.1.

Open

Select Open to access archived data files for each logger in
your network.
Shortcuts: You can also click the Open icon
Ctrl+O to open archived files.
110
or press
