The Data Map displays all data sets opened in History View,
saved in the current project file, and includes nodes for each
sensor in the data set.
Clicking the sensor label removes the data from the graph.
When the label is black, the data is not displayed on the
graph. The sensor data plot color is matched to the color of
the sensor label in the Data Map.
Each data set is preceded by a Logger icon , which can
be expanded or collapsed to display the associated sensor
data.
Clicking the Tree icon in the lower graph toolbar removes
the Data Map pane altogether allowing a full screen graph
view.
Data Map

Figure 37: Data Map

4.2.5.

DataNet Toolbar Icons

This section outlines all of the toolbar icons available in the
software.
